BIXOLON BCD-1000 User Manual

Ver. 1.01
- 11 -
BCD-2000/3000
5-2-2 Device fonts for controlling Customer Display
Font Name
Font Size
FontControl
7 point
FontControlA
• This Windows driver supports the special functions as shown in the following table.
Select FontControl font first and use the characters in the table to use the special
functions.
Take care as this function is not for displaying general texts.
Character
Function Description
0
Initialize display.
1
Clear display screen.
2
Clear 1st line.
3
Clear 2nd line.
4
Clear 3rd line.
5
Clear 4nd line.
6
Selects overwrite mode as the screen display mode.
7
Selects vertical scroll mode as the screen display mode.
8
Selects horizontal scroll mode as the screen display mode.
A
Set 1st line blinking.
B
Set 2nd line blinking.
C
Set 3rd line blinking.
D
Set 4th line blinking.
E
Clear 1st line blinking.
F
Clear 2nd line blinking.
G
Clear 3rd line blinking.
H
Clear 4th line blinking.
I
Set cursor ON
J
Set cursor Off
K
Display NV Logo #1 (Position: Left-most of the first line)
L
Display NV Logo #2 (Position: Left-most of the first line)
M
Display NV Logo #3 (Position: Left-most of the first line)
O
Display NV Logo #4 (Position: Left-most of the first line)
a
Clear display screen.
b
Clear 1st line.
c
Clear 2nd line.
d
Clear display screen blink.
e
Set display screen blink interval (500ms)
f
Set display screen blink interval (1000ms)
g
Set display screen blink interval (2000ms)
h
Set display screen blink interval (3000ms)
l
Enable reversed character. (US r n)
m
Disable reversed character. (US r n)
n
Start/End macro definition.
o
Execute and quit defined macro.
* If the “FontControl” font is selected and “a” is entered, the screen clearing operation
is activated. (Does not entail the printing of the character “a”)
