BIXOLON SPP-R200II Command Manual

SPP-R200II Command Manual
Rev. 1.00 BIXOLON
- 11 -
FF
Function:
Form feed (in page mode)
Code:
ASCII
FF
Hex
0C
Decimal
12
Range:
None
Default:
None
Description:
This commands prints all data collected in the printer buffer In page mode. After completion of printing, the printer is
returned to standard mode.
Remarks:
■ The printer is returned to standard mode after completion of printing.
■ After being printed, all of the existing data in the printer buffer is evacuated and the print position changes to the
beginning of the line.
■ This command works in page mode enabled by ESC L
Differences:
■ After completion of printing, the printer does not clear the printer buffer and the print position moves to the beginning
of the line.

BIXOLON SPP-R200II Specifications

General

Type	Mobile printer
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Compatible operating systems	Windows XP/Vista/Server 2003/2008/7/8\\r OPOS\\r Linux CUPS
Flash memory	32 MB
Internal memory	64 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Maximum printing width	50 mm
USB port	Yes
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Dimensions (WxDxH)	79.5 x 43.6 x 126.7 mm
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 80 %
Ethernet LAN	No
Battery voltage	7.4 V
Power source type	Battery
Battery life (max)	6.2 h
