BIXOLON SPP-R200II Command Manual

SPP-R200II Command Manual
Rev. 1.00 BIXOLON
- 13 -
DLE
Function:
Set real-time command mode
Code:
ASCII
DLE
Hex
10
Decimal
16
Range:
None
Default:
None
Description:
This command enables commands to be operable in real-time.
Remarks:
■ A single command following this command is regarded as a real time command.
■ The real time command is stored into the receive buffer and executed with higher priority than other commands.
■ If this command is processed as a parameter of the other command, the data following this command might bring
about the unwanted result.
■ The commands that are allowed to be executed in real time mode vary depending on the printer model.
Differences:
■ Commands that can be executed in real time mode: EOT, GS r, GS I, GS I b

BIXOLON SPP-R200II Specifications

General

Type	Mobile printer
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Compatible operating systems	Windows XP/Vista/Server 2003/2008/7/8\\r OPOS\\r Linux CUPS
Flash memory	32 MB
Internal memory	64 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Maximum printing width	50 mm
USB port	Yes
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Dimensions (WxDxH)	79.5 x 43.6 x 126.7 mm
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 80 %
Ethernet LAN	No
Battery voltage	7.4 V
Power source type	Battery
Battery life (max)	6.2 h
