BIXOLON SPP-R200II Command Manual

SPP-R200II Command Manual
Rev. 1.00 BIXOLON
- 25 -
ESC D
Function:
Set horizontal tab position
Code:
ASCII
ESC
D
n1...nk
NUL
Hex
1B
44
n1...nk
00
Decimal
27
68
n1...nk
0
Range:
1 ≤ n ≤ 255 , 0 ≤ k ≤ 32
Default:
n=8, 16, 24, 32, 40,....., 232, 240, 248
Description:
■ This command sets the horizontal tab position.
• n defines the number of columns from the beginning of the line to the horizontal tab setting.
• k denotes the number of horizontal tab positions to be set.
• The horizontal tab position is stored as a value of [character width x n] measured form the beginning of the line.
Remarks:
■ The data [n]k signifying the set position is transmitted in the ascending order and ends with a NUL code.
■ ESC D NUL cancels all horizontal tab positions.
■ Tab position is set at the value of [character width x n] from the beginning of the line.
■ The character width includes the space to the right of the character, and it will be twice the normal character when the
double width characters are selected.
■ If the data [n]k is equal to or smaller than the preceding data [n]k-1, the horizontal tab setting has been completed.
■ Up to 32 horizontal tabs can be set, the data exceeding this limit is processed as normal ones.
■ Even if the character width is changed after setting the horizontal tab positions, the horizontal tab positions remain
unchanged.
Differences:
None

BIXOLON SPP-R200II Specifications

General

Type	Mobile printer
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Compatible operating systems	Windows XP/Vista/Server 2003/2008/7/8\\r OPOS\\r Linux CUPS
Flash memory	32 MB
Internal memory	64 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Maximum printing width	50 mm
USB port	Yes
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Dimensions (WxDxH)	79.5 x 43.6 x 126.7 mm
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 80 %
Ethernet LAN	No
Battery voltage	7.4 V
Power source type	Battery
Battery life (max)	6.2 h
