BIXPY K-1 MOTOR SPECIFICATIONS
MOTOR SIZE
Width along motor body: 80mm 3.15”
Width along the output nozzle: 91.5 mm 3.60”
Length: 230mm 9.05”
Height (including top fin adapter): 155 mm 6.10”
Weight: 1270 grams 2.8 lb
POWER OUTPUT
Max. output using PP-378 V4: 400 watts
Thrust equivalent: Up to 33 lbs 15 kg
Water movement: ~130 GPM ~500 L/min
Max. output using PP-768: 450 watts
Thrust equivalent: Up to 38 lbs 17 kg
Water movement: ~145 GPM ~550 L/min
CONNECTORS: Bixpy 5 pin connector - rated for max. 30V usage with Bixpy batteries
MOTOR IP RATING: IP68 rated
CORROSION RATING: All components are fresh and saltwater resistant
