Bizerba A 400 - Page 142

A 400 / A 400 FB
054.98.3.1013
Spare parts list No.
90.077
Series (code No.)
2
Text page
Amendment: 07/2012
Bitte unbedingt 11--stellige Bestell--Nr. angeben • Please always indicate 11 digit Order No. • Absolument nécessaire d’indiquer No. de commande
(11 c hiffres)
• Favorisca specificarci sempre il N. di ordine a11cifre • Es imprescindible que citen el No. de pedido (11 guarismos)
Number in drawing
X
from status
onwards
X
Designation
X
Piece
X
Order number
X
10--255 001 MOTOR HOUSING PREASSEMBLED
10--255--256 60540100202 001 MOTOR HOUSING
(FROM DEVICE--NO. 1332927)
10--255--257 60540105500 001 BLADE BUSHING COMPL.
(DEVICE--NO. 1276988 -- 1332926)
60223505501 001 BLADE BUSHING COMPL.
(FROM DEVICE--NO. 1332927)
10--255--257--1 60223500402 001 BLADE BUSHING PREASSEMBLED
(UP TO DEVICE--NO. 1276987)
60223500403 001 BLADE BUSHING PREASSEMBLED
(DEVICE--NO. 1276988 -- 1332926)
10--255--257--1--1 60223500502 001 BLADE BUSHING
(UP TO DEVICE--NO. 1276987)
60223500503 001 BLADE BUSHING
(DEVICE--NO. 1276988 -- 1332926)
10--255--257--1--3 56360940000 002 GROOVED BALL BEARING DIN 625 6004--2RS
10--255--257--1--5 57778720000 002 RETAINING RING JV 42X1.75
10--255--257--1--7 60223500601 001 BLADE SHAFT STAINLESS STEEL
(FROM DEVICE--NO. 1276988)
10--255--257--1--9 60540104900 001 SUPPORTING WASHER
10--255--257--1--1 1 50001680000 003 DISC SPRING 31,7X20,4X0,3
10--255--257--1--13 50003130000 001 SHAFT SEAL BA SL20X42X10--NBR
10--255--257--1--15 94008900058 000 KLUEBERSYNTH UH1 64--62/25KG
10--255--257--3 60540100300 001 MOUNTING
(4 HOLE; UP TO DEVICE--NO. 1276987)
60540100301 001 MOUNTING
(3 HOLE; DEVICE--NO.1276988 -- 1332926)
60223500302 001 MOUNTING
(3 HOLE; FROM DEVICE--NO. 1332927)
10--255--257--5 60223501300 001 LABYRINTH SEAL I
10--255--257--7 57454180000 003 COUNTERSUNK SCREW DIN 965--M4X8--T20--A2--70
10--255--257--9 56362540000 001 GROOVED BALL BEARING DIN 625 61812--2RS1
(D=78MM, DEVICE--NO.1276988 -- 1332926)
56362660000 001 GROOVED BALL BEARING DIN 625 69120--RDZ
(D=85MM; FROM DEVICE--NO. 1332927)
10--255--257--11 50282670000 001 BALL BEARING SHIM WA. 84X74X0,6
10--255--260 57767060000 004 SPR. LOCK WASHER DIN 128--A6--FST
10--255--261 57736160000 004 SOCKET HEAD SCREW DIN 912--M6X16--8.8
4
