A 400 / A 400 FB
054.98.3.1013
Spare parts list No.
90.077
Series (code No.)
7
Text page
Amendment: 07/2012
Bitte unbedingt 11--stellige Bestell--Nr. angeben • Please always indicate 11 digit Order No. • Absolument nécessaire d’indiquer No. de commande
(11 c hiffres)
• Favorisca specificarci sempre il N. di ordine a11cifre • Es imprescindible que citen el No. de pedido (11 guarismos)
Number in drawing
X
from status
onwards
X
Designation
X
Piece
X
Order number
X
20 60540239702 001 CARRIAGE 400 JPN
60540240005 001 CARRIAGE 400
20--2 60540242000 001 CARRIAGE SUPP. PREASSEMBLED SHORT
20--4 60540242100 001 BEARING ASS.
20--6 57431250000 003 HEXAGON SCREW DIN 933--M6X25--A2--70
20--8 56739060000 003 WASHER DIN 125--A 6,4--A2--70
20--10 50003410000 002 DEFLECTOR RING A20/30 7/4
20--12 56368320000 001 ANGULAR BALL BEARING DIN 628 3202 ATN9
20--14 56366420000 001 SELF--ALIG. BALL BEARING DIN 630--2202.2RS
20--50 60540220901 001 FEED SPINDLE ASSEMBLED
(CARRIAGE 200, FROM DEVICE--NO. 1332927)
60540240301 001 FEED SPINDLE ASS.
(CARRIAGE 400, FROM DEVICE--NO. 1332927)
60540260301 001 FEED SPINDLE ASS.
(CARRIAGE 600, FROM DEVICE--NO. 1332927)
20--50--4 60540260500 002 RING
20--50--30 60540272400 001 NUT
20--50--32 60540272200 001 CLAMPING PIECE
20--50--34 60540272500 002 THREADED PIN
20--50--36 50275090000 002 PRESSURE SPRING VD--097
20--50--38 56400850000 002 LOCKNUT DIN 985--M5--A2--70
20--50--40 95972840000 000 SCREW SEALING ADHESIVE LOCTITE 648 10M
20--80 57778700000 002 RETAINING RING DIN 472--I 35X1.5 V
20--82 60540272001 001 WASHER
20--84 50281100000 002 DISC SPRING 34.6X22.4X0.5
20--86 56709550000 001 PARALLEL KEY DIN 6885--3--A5X3X16
20--88 60540260700 001 GEAR WHEEL
20--90 60540260801 001 WASHER
20--92 60540240701 001 GUIDE RAIL
20--94 57630420000 004 COUNTERSUNK SCREW DIN 963--M4X8--A2--70
20--96 56360600000 002 GROOVED BALL BEARING DIN 625 6000--2Z
20--98 60540261000 001 BOLT
20--100 60540261100 001 GEAR WHEEL
20--102 57773750000 001 RETAINING RING DIN 471--10X1
20--104 60540261200 001 GEAR WHEEL
20--106 56083100000 001 SETSCREW DIN 913--M4X4--45H
20--108 52022250000 001 GEAR MOTOR DC GR 42X40 RE30
(40V/I4,5:1; UP TO DEVICE--NO. 1332926)
52022320000 001 GEAR MOTOR DC GR 42X40 RE30
(40V/I6,25:1; UP TO DEVICE--NO. 1332926)
52022270000 001 GEAR MOTOR DC GR 42X40RE30
(24V/I4,5:1 FROM DEV.--NO. 1332927, OLD)
52022290000 001 GEAR MOTOR DC GR 42X40 RE30
(24V/I6,25:1; FROM DEV.--NO. 1332927, NEW
FROM SOFTW.VERSION D2 605469021 11)
52022330000 001 GEAR MOTOR DC GR42X40 RE30/I=20,23:1
(24V WITH INT. INTERF. ELIM./I20,25:1
SPECIAL CARRIAGE FOR SALMON DNK)
