Bizerba A 400 - Page 156

A 400 / A 400 FB
054.98.3.1013
Spare parts list No.
90.077
Series (code No.)
16
Text page
Amendment: 07/2012
Bitte unbedingt 11--stellige Bestell--Nr. angeben • Please always indicate 11 digit Order No. • Absolument nécessaire d’indiquer No. de commande
(11 c hiffres)
• Favorisca specificarci sempre il N. di ordine a11cifre • Es imprescindible que citen el No. de pedido (11 guarismos)
Number in drawing
X
from status
onwards
X
Designation
X
Piece
X
Order number
X
27--20 60541080000 003 MET AL SHEET INSERT COMPLETE
27--20--10 60541081900 003 SACER COMPLETE
27--20--20 60541081200 003 SWING SP ACER COMPLETE
27--20--30 56400850000 006 LOCKNUT DIN 985--M5--A2--70
27--20--60 38033783000 006 TENSION SPRING
27--30 60541082100 001 ANGLE
27--40 60541085800 002 SP ACER
27--50 57431420000 002 HEXAGON SCREW DIN 933--M6X45--A2--70
28 60370161900 006 LOCKING HANDLE SMALL M5 PRE--ASSEMBLED
30 001 DRIVE COMPL. FOR TABLE
30--10 60540300605 001 DRIVE HOUS.TABLE+DISPLAY BOTTOM
(FROM DEVICE--NO. 10516522)
60540300805 001 DRIVE HOUS. TABLE+DISPLA Y TOP
(FROM DEVICE--NO. 10516522)
30--20 60540301700 001 BAR
30--22 57737250001 002 SOCKET HEAD SCREW DIN 912--M8X25--8.8--A4V
30--26 60360313203 004 FOOT COMPL.
30--32 52022230000 001 GEAR MOTOR DC EPG 40V EGP 132/468
(42V / I 35:1; PLANTOGEAR 460S,
90 VISCOSITY , 1/4 L)
30--36 57442200000 003 COUNTERSUNK SCREW DIN 7991--M8X20--A2--70
30--37 50003610000 001 O--SEAL 54X3,0
30--40 71011470000 001 CABLE GLAND PG 9 DIN 46320
30--41 60546100300 001 CABLE BACKPLANE INTERMEDIATE BOARD 1 A40
30--60 60540301800 001 CRANK ASSEMBLED
30--68 50001870000 001 CLAMPING SET 16X20 PSV3001
30--69 60540302400 001 SP ACER RING
30--70 57736161000 006 SOCKET HEAD SCREW DIN 912--M6X16--10.9
30--74 60540302001 001 CLAMPING RING
30--101 57778720000 002 RETAINING RING JV 42X1.75
30--102 56360940000 002 GROOVED BALL BEARING DIN 625 6004--2RS
30--103 38004459000 000 LOCTITE 648
30--108 60540302100 001 SHAFT
30--109 60540302202 001 BUSHING
30--200 60540302500 001 ROCKER ARM COMPL.
30--266 60540303201 001 LINKAGE LONG
30--267 60540303300 002 FLANGE BUSHING
30--268 60540303400 002 FLANGE BUSHING
30--269 57736200000 002 SOCKET HEAD SCREW DIN 912--M6X20--8.8
30--270 60540303500 001 THRUST WASHER
30--271 95972840000 000 SCREW SEALING ADHESIVE LOCTITE 648 10M
30--276 60540303801 001 METAL BLOCK -- COUPLING SHORT
30--277 60540303900 002 MET AL RING
30--278 57736160000 002 SOCKET HEAD SCREW DIN 912--M6X16--8.8
30--279 60540303600 002 THRUST WASHER
30--280 95972840000 000 SCREW SEALING ADHESIVE LOCTITE 648 10M
4
