Bizerba A 400 - Page 159

A 400 / A 400 FB
054.98.3.1013
Spare parts list No.
90.077
Series (code No.)
19
Text page
Amendment: 07/2012
Bitte unbedingt 11--stellige Bestell--Nr. angeben • Please always indicate 11 digit Order No. • Absolument nécessaire d’indiquer No. de commande
(11 c hiffres)
• Favorisca specificarci sempre il N. di ordine a11cifre • Es imprescindible que citen el No. de pedido (11 guarismos)
Number in drawing
X
from status
onwards
X
Designation
X
Piece
X
Order number
X
30--530--543 60240313200 001 HELICAL GEAR COMP.
30--530--544 57734060000 001 SOCKET HEAD SCREW DIN 912--M4X6--8.8
30--530--545 95972940000 000 SCREW SEALING ADHESIVE LOCTITE 243 10ML
30--545 56806470000 003 OVAL--HEAD SCREW DIN 7985--M4X25--A2--70
30--546 57767040000 003 SPR. LOCK WASHER DIN 128--A4--FST
30--550 60540307301 001 MOTOR PEDESTAL FOR CHAIN FRAME DRIVE
60540920601 001 MOTOR PEDESTAL FRA FOR CHAIN FRAME DRIVE
(FRA)
30--551 52004030000 001 MOTOR D.C. 24V L300 GR 42X40 RE30
30--552 56805731000 004 OVAL--HEAD SCREW DIN 7985--M3X8--T10--8.8
30--553 57767030000 004 SPR. LOCK WASHER DIN 128--A3--FST
30--555 57736120000 002 SOCKET HEAD SCREW DIN 912--M6X12--8.8
30--556 57767060000 002 SPR. LOCK WASHER DIN 128--A6--FST
30--560 60240303800 001 WORM
30--561 56083100000 001 SETSCREW DIN 913--M4X4--45H
30--562 95972940000 000 SCREW SEALING ADHESIVE LOCTITE 243 10ML
30--563 94008900058 000 KLUEBERSYNTH UH1 64--62/25KG
30--570 60540307400 001 TRANSDUCER INSTALLATION COMPL.
(UP TO DEVICE--NO. 2162294)
60540306800 001 TRANSDUCER ASSEMBLED A400
(FROM DEVICE--NO. 2162295)
30--570--576 60540307601 001 FASTENING PLA TE FOR TRANSDUCER
30--570--578 52004021000 001 SHAFT ENCODER VS 8D UL
(UP TO DEVICE--NO. 2162294)
60540306901 001 SHAFT ENCODER A 400
(FROM DEVICE--NO. 2162295)
30--570--579 60540307800 001 INCREMENTAL ENCODER MOUNTING
(UP TO DEVICE--NO. 2162294)
60540307801 001 INCREMENTAL ENCODER MOUNTING
(FROM DEVICE--NO. 2162295)
30--570--580 57767030000 004 SPR. LOCK WASHER DIN 128--A3--FST
30--570--581 56805731000 004 OVAL--HEAD SCREW DIN 7985--M3X8--T10--8.8
(UP TO DEVICE--NO. 2162294)
56806270000 004 OVAL--HEAD SCREW DIN 7985--M3X8--A2--70
(FROM DEVICE--NO. 2162295)
30--570--582 60240300800 001 THRUST WASHER
(UP TO DEVICE--NO. 2162294)
60820308601 001 DISK
(FROM DEVICE--NO. 2162295)
