Bizerba A 400 - Page 162

A 400 / A 400 FB
054.98.3.1013
Spare parts list No.
90.077
Series (code No.)
22
Text page
Amendment: 07/2012
Bitte unbedingt 11--stellige Bestell--Nr. angeben • Please always indicate 11 digit Order No. • Absolument nécessaire d’indiquer No. de commande
(11 c hiffres)
• Favorisca specificarci sempre il N. di ordine a11cifre • Es imprescindible que citen el No. de pedido (11 guarismos)
Number in drawing
X
from status
onwards
X
Designation
X
Piece
X
Order number
X
30--723 60540310800 001 BOTTOM PLATE PRE--ASSEMBL.
30--724 67501384600 001 WARNING PLATE CSA
30--726 56818430000 012 SELF--TAPP.SCREW DIN 7500--CM4X8--T20--ST
30--727 56739080000 001 WASHER DIN 125--A 8.4--A2--70
30--728 57350120000 001 HEXAGON SCREW DIN 933--M8X12--8.8
30--729 60540310900 001 COVER PLATE
30--801 60540316801 001 BEARIG SLEEVE MOUNT
30--804 94008900058 000 KLUEBERSYNTH UH1 64--62/25KG
30--805 95972840000 000 SCREW SEALING ADHESIVE LOCTITE 648 10M
30--806 60540316000 001 PRESSURE SPRING 85 MM
(UP TO DEVICE--NO. 1428858)
60540316001 001 PRESSURE SPRING 100 MM
(FROM DEVICE--NO. 1428859)
30--810 60540317001 001 MAGNET HOLDER ASSEMBLED
(FROM DEVICE--NO. 1428858)
30--810--811 60540317100 001 MAGNET HOLDER
(UP TO DEVICE--NO. 1428858)
60540317102 001 MAGNET HOLDER
(FROM DEVICE--NO. 1428859)
30--810--820 71150710000 001 MAGNET TRAVEL TDS--K10SL
(UP TO DEVICE--NO. 1428858)
71150780000 001 MAGNET TRAVEL TDS--K12E
(FROM DEVICE--NO. 1428859)
30--810--821 56805330000 003 OVAL--HEAD SCREW DIN 7985--M3X6--4.8
30--810--822 57767030000 003 SPR. LOCK WASHER DIN 128--A3--FST
30--810--830 60540317200 001 OPERATING ANGLE PLATE
(UP TO DEVICE--NO. 1428858)
60540317202 001 SWITCH ANGLE
(FROM DEVICE--NO. 1428859)
30--810--831 56350100000 001 PARALLEL NOTCHED PIN 2 X10
(UP TO DEVICE--NO. 1428858)
56359300000 001 GROOVED PIN DIN 1473--3X12--A2
(FROM DEVICE--NO. 1428859)
30--810--835 60546101200 001 CABLE MAGNET LOCKING --> BACKPLANE A400
30--810--840 71027080000 001 SWITCH
30--810--841 56805470000 002 OVAL--HEAD SCREW DIN 7985--M4X20--5.8
30--810--842 56739040000 002 WASHER DIN 125--A 4.3--A2--70
30--810--843 60533302001 001 NUT PLATE
