BK Precision 8600 - SERVICE INFORMATION

83
Model
8610
8612
8614
8616
Input Ratings
Input Voltage
0 – 120 V
0 – 500 V
0 – 120 V
0 – 500 V
Input
Current
Low
0 – 12 A
0 – 3 A
0 – 24 A
0 – 6 A
High
0 – 120 A
0 – 30 A
0 – 240 A
0 – 60 A
Input Power
750 W
1500 W
1200 W
Minimum
Operating
Voltage
Low
0.12 V at 12 A
0.36 V at 3 A
0.15 V at 24 A
0.36 V at 6 A
High
1.2 V at 120 A
3.6 V at 30 A
1.5 V at 240 A
3.6 V at 60 A
CV Mode
Range
Low
0 – 18 V
0 – 50 V
0 – 18 V
0 – 50 V
High
0 – 120 V
0 – 500 V
0 – 120 V
0 – 500 V
Resolution
Low
0.1 mV
1 mV
0.1 mV
1 mV
High
1 mV
10 mV
1 mV
10 mV
Accuracy
Low
±(0.025%+0.05%FS)
±(0.025%+0.025
%FS)
±(0.025%+0.05%FS)
High
±(0.025%+0.05%FS)
CC Mode
Range
Low
0 – 12 A
0 – 3 A
0 – 24 A
0 – 6 A
High
0 – 120 A
0 – 30 A
0 – 240 A
0 – 60 A
Resolution
Low
1 mA
0.1 mA
1 mA
0.1 mA
High
10 mA
1 mA
10 mA
1 mA
Accuracy
Low
±(0.05%+0.1%FS)
±(0.05%+0.05%FS)
±(0.05%+0.1%
FS)
±(0.05%+0.05%FS)
High
±(0.05%+0.1%FS)
±(0.05%+0.05%FS)
±(0.05%+0.1%
FS)
±(0.05%+0.05%FS)
CR Mode
Range
Low
0.02 Ω – 10 Ω
0.15 Ω – 10 Ω
0.01 Ω – 10 Ω
0.1 Ω – 10 Ω
High
10 Ω - 7.5 kΩ
Resolution
16 bit
Accuracy
Low
0.01%+0.08 S
High
0.01%+0.0008 S
CW Mode
Range
750 W
1500 W
1200 W
Resolution
10 mW
100 mW
Accuracy
0.2% + 0.2%FS
