6
ENGLISH
(Original instructions)
u Press the rear paper clamp lever (4) downwards and
locate it in the retaining groove.
Fitting and removing the dustbag (g. C)
u Fit the dustbag (6) over the dust extraction outlet (2).
u Slide the dustbag onto the tool and make sure that it is
securely located.
u To remove the dustbag, pull it to the rear and off the outlet.
Use
Warning! Let the tool work at its own pace. Do not overload.
KA320E - Variable speed control
The variable speed control allows you to adapt the speed of
the tool to the workpiece material.
u Set the control knob (5) to the desired setting. Use a high
speed for wood, medium speed for veneer and synthetics
and low speed for acrylic glass, non-ferrous metals and for
removing paints.
Switching on and off (g. D)
u To switch the tool on, press the front part I of the on/off
switch (1).
u To switch the tool off, press the rear part O of the on/off
switch.
Emptying the dustbag (g. C)
The dustbag (6) should be emptied every 10 minutes of use.
u Pull the dustbag (6) to the rear and off the tool.
u Hold the spout down and shake the dustbag (6) to empty
the contents.
u Slide the dustbag (6) onto the tool and make sure that it is
securely located.
Hints for optimum use (g. E)
u Always hold the tool with both hands.
u Do not exert too much pressure on the tool.
u Regularly check the condition of the sanding sheet.
Replace when necessary.
u Always sand with the grain of the wood.
u When sanding new layers of paint before applying another
layer, use extra ne grit.
u On very uneven surfaces, or when removing layers of
paint, start with a coarse grit. On other surfaces, start with
a medium grit. In both cases, gradually change to a ne
grit for a smooth nish.
u Consult your retailer for more information on available
accessories.
Accessories
The performance of your tool depends on the accessory used.
BLACK+DECKER and Piranha accessories are engineered to
high quality standards and designed to enhance the
performance of your tool. By using these accessories you will
get the very best from your tool.
Maintenance
Your BLACK+DECKER corded tool has been designed to
operate over a long period of time with a minimum of
maintenance. Continuous satisfactory operation depends
upon proper tool care and regular cleaning.
Warning! Before performing any maintenance on the tool,
switch off and unplug the tool.
u Regularly clean the ventilation slots in your tool and
charger using a soft brush or dry cloth.
u Regularly clean the motor housing using a damp cloth. Do
not use any abrasive or solvent-based cleaner.
Mains plug replacement (U.K. & Ireland only)
If a new mains plug needs to be tted:
u Safely dispose of the old plug.
u Connect the brown lead to the live terminal in the
new plug.
u Connect the blue lead to the neutral terminal.
Warning! No connection is to be made to the earth terminal.
Follow the tting instructions supplied with good quality
plugs. Recommended fuse: 5 A.
Protecting the environment
Separate collection. Products and batteries
marked with this symbol must not be disposed of
with normal household waste.
Products and batteries contain materials that can be recov-
ered or recycled reducing the demand for raw materials.
Please recycle electrical products and batteries according to
local provisions. Further information is available at
www.2helpU.com
Technical data
KA310 (Type 1 ) KA320E (Type 1)
Input voltage
V
ac
230 230
Power input
W 240 240
Oscillations (no load)
min
-1
30,000
14,000 - 30,000
Orbits (no load) min
-1
15,000 7,000 - 15,000
Sanding base surface mm 90 x 187 90 x 187
Weight kg
1.3
1.3
Level of sound pressure according to EN 62841:
L
pA
(sound pressure) 86.5 dB(A), Uncertainty (K) 3 dB(A)
L
WA
(sound power) 97.5 dB(A), Uncertainty (K) 3 dB(A)
Vibration total values (triax vector sum) according to EN 62841:
Vibration emission value (a
h
) 9.8 m/s
2
, uncertainty (K) 1.5 m/s
2
