17
CHAPTER 3: Before You Install: Getting Started
Figure 3-1. Examples of SCSI-bus termination.
Terminated Device
Up to 25 m (82 ft.)
Terminated
Device
Terminated
Device
Unterminated
Devices
Unterminated
Devices
Terminated
Cable
Terminated Cable
All Devices Unterminated
All Devices Unterminated
INTERNAL
ONLY
SINGLE EXTERNAL
ONLY
INTERNAL/
EXTERNAL
MULTIPLE
EXTERNAL ONLY
Adapter
(Terminated)
Adapter
(Terminated)
Adapter
(Unterminated)
Adapter
(Terminated)
