CONFIGURATION
OFF ON ON OFF OFF ON OFF 3328
OFFONONOFFOFFONON3392
OFF ON ON OFF ON OFF OFF 3456
OFF ON ON OFF ON OFF ON
3520
OFF ON ON OFF ON ON OFF 3584
OFF ON ON OFF ON ON ON 3648
OFF ON ON ON OFF OFF OFF 3712
OFFONONONOFFOFFON3776
OFF ON ON ON OFF ON OFF 3840
OFFONONONOFFONON
3904
OFF ON ON ON ON OFF OFF 3968
OFFONONONONOFFON4032
OFF ON ON ON ON ON OFF 4096
OFFONONONONONON4160
ON OFF OFF OFF OFF OFF OFF 4224
ON OFF OFF OFF OFF OFF ON
4288
ON OFF OFF OFF OFF ON OFF 4352
ON OFF OFF OFF OFF ON ON 4416
ON OFF OFF OFF ON OFF OFF 4480
ON OFF OFF OFF ON OFF ON 4544
ON OFF OFF OFF ON ON OFF 4608
ON OFF OFF OFF ON ON ON
4672
ON OFF OFF ON OFF OFF OFF 4736
ON OFF OFF ON OFF OFF ON 4800
ON OFF OFF ON OFF ON OFF 4864
ON OFF OFF ON OFF ON ON 4928
ON OFF OFF ON ON OFF OFF 4992
ON OFF OFF ON ON OFF ON
5056
ON OFF OFF ON ON ON OFF 5120
ON OFF OFF ON ON ON ON 5184
ON OFF ON OFF OFF OFF OFF 5248
ON OFF ON OFF OFF OFF ON 5312
ON OFF ON OFF OFF ON OFF 5376
S4-2 S4-3 S4-4 S4-5 S4-6 S4-7 S4-8 Data Rate (kbps)
724-746-5500 | blackbox.com
Page 14
Black Box Long Range Ethernet Extender
OFF OFF ON OFF OFF OFF OFF 1152
OFF OFF ON OFF OFF OFF ON
1216
OFF OFF ON OFF OFF ON OFF 1280
OFF OFF ON OFF OFF ON ON 1344
OFF OFF ON OFF ON OFF OFF 1408
OFF OFF ON OFF ON OFF ON 1472
OFF OFF ON OFF ON ON OFF 1536
OFF OFF ON OFF ON ON ON
1600
OFF OFF ON ON OFF OFF OFF 1664
OFF OFF ON ON OFF OFF ON 1728
OFF OFF ON ON OFF ON OFF 1792
OFF OFF ON ON OFF ON ON 1856
OFF OFF ON ON ON OFF OFF 1920
OFF OFF ON ON ON OFF ON
1984
OFF OFF ON ON ON ON OFF 2048
OFF OFF ON ON ON ON ON 2112
OFF ON OFF OFF OFF OFF OFF 2176
OFF ON OFF OFF OFF OFF ON 2240
OFF ON OFF OFF OFF ON OFF 2304
OFF ON OFF OFF OFF ON ON
2368
OFF ON OFF OFF ON OFF OFF 2432
OFF ON OFF OFF ON OFF ON 2496
OFF ON OFF OFF ON ON OFF 2560
OFFONOFFOFFONONON2624
OFF ON OFF ON OFF OFF OFF 2688
OFF ON OFF ON OFF OFF ON
2752
OFF ON OFF ON OFF ON OFF 2816
OFF ON OFF ON OFF ON ON 2880
OFF ON OFF ON ON OFF OFF 2944
OFF ON OFF ON ON OFF ON 3008
OFF ON OFF ON ON ON OFF 3072
OFF ON OFF ON ON ON ON
3136
OFF ON ON OFF OFF OFF OFF 3200
OFF ON ON OFF OFF OFF ON 3264
S4-2 S4-3 S4-4 S4-5 S4-6 S4-7 S4-8 Data Rate (kbps)
