16
10/100 ETHERNET SWITCHES
The front and back panels of the 16-Port
10/100 Ethernet Switch are shown in
Figure 2-4.
Figure 2-4. 10/100 Ethernet Switch, 16-Port.
LED panel
RJ-45
connectors
Power
connector
Power LED
100M LEDs
Link/
Activity
LEDs
