Fig 2.2c LBH100A-P with 100Mb SC
Connector
The front side of the unit has two twisted-pair
10/100Mb switch ports and one 10 or 100Mb
fiber port. Both the RJ-45 ports of the LBH100A and LBH110A Series Media Converter
Switches support auto-cross (MDIX) operation performing the auto-cross function under
auto-negotiation mode only. The 10Mb fiber (LBH110 models) are factory configured at
Half-duplex, and 100Mb (LBH100 models) are factory configured at Full-Duplex.
