MINI USER MANUAL
Black Jack Trailer Jack® Mini User Manual V1 ©
1. SPECIFICATIONS
Maximum Load Capacity 1000 kg
Stroke Length Max stroke length 18” (450mm)
Foot Plate Removable 110mm diameter foot plate
Handle Manual crank override
Tube Diameter 50mm outer Dimension
Construction Steel tubes and plate and polypropylene cover
Motor Type Sealed encapsulated brushless motor
Finish Powder coat tube, zinc plated inner and drop tubes
Overall Dimensions H 830 x W 110 x D 170mm
Voltage Rating 12V DC
Circuit Protection Circuit Breaker 30amp short stop, auto resettable
ignition protected
Current Rating Maximum 28A (Extended), 6A (Retracted)
IP Rating Minimum IP55
2. INTRODUCTION
Congratulations on your new Black Jack!
The Black Jack Trailer Jack is rated to support up to 1000kg trailer tongue weight and
can t directly into a standard 50mm jockey wheel clamp.
The Black Jack features an LED light to illuminate the hitch area at night and a built-in
levelling gauge. It also features a high quality cover to protect it against dirt, moisture
and harsh conditions that exist behind a tow vehicle.
The soft ground Foot Pad can be used for more stability on soft grass, mud or other
unstable surfaces.
