STEP 02
Place the bottom shelf and secure it with one (1) large thumbscrew to
between the two legs on the le. Use one (1) small thumbscrew to attach the
shelf and the propane tank holder in between the two lockable castor wheels
on the right. Then, attach the propane tank hanger with one (1) M6X70 bolt
and one (1) M6 nut.
STEP 03
With the help of another person, place the griddle on it’s feet. Then, install the
paper towel holder by sliding it into the slot beneath the right side shelf. Secure
it using one (1) M6X12 screw and two (2) washers. Next, push the knobs into
place and screw on the ingition button (be careful not to over tighten).
STEP 04
Attach two (2) side shelf brackets to the right side of the griddle unit with
four (4) M6X12 bolts. Then repeat this step on the le side of the griddle unit
with four (4) M6X12 screws.
Insert one AA battery (not included)
into the battery socket with the
positive terminal facing out, and
then screw on the Ignition Button
until tight, be careful not to
over tighten.
36” Griddle Cooking Station | Parts & Assembly
03
