| OWNER’S MANUALASSEMBLY GUIDEMODEL: 
1
Griddle body (1 piece)
2
Griddle top (1 piece)
3
Hood (1 piece)
4
Bottom tray (1 piece)
5
Left side shelf
(1 piece)
6
Right side shelf
(1 piece)
7
Hood handle
(1 piece)
8
Hood handle
bezels (2 pieces)
9
Drawer
assembly (3 pieces)
10
Drawer handles
(3 pieces)
11
Left leg
assembly (1 piece)
12
Right leg
assembly (1 piece)
13
Caster wheels
(4 pieces)
14
Control knobs
(5 pieces)
15
Power cord
bracket (1 piece)
16
Grease cup
(1 piece)
17
Side shelf
bracket (a) (2 pieces)
18
Side shelf
bracket (b) (2 pieces)
19
LPG hook
(1 piece)
20
LPG support
(1 piece)
21
Hardware pack (1 piece)
a. M6x20 screws (2 pieces)
b. Washers (8 pieces)
c. Lid spacers (2 pieces)
d. M6 Step bolts (8 pieces)
e. M5x15 screws (12 pieces)
f. M6 lock nuts (2 pieces)
g. M6x12 screws (17 pieces)
h. Side shelf pegs (8 pieces)
i. M6x15 screws (8 pieces)
j. M6 Thumbscrews (4 pieces)
21a
21e
21h
21i 21j
21f 21g
21b 21c 21d

