STEP 11
Insert the inner shelf leg into the cart base hole. Rest the
shelf on the four (4) inner shelf brackets.
STEP 12
Attach the left cabinet door assembly to the cart by first
❶ ❶
inserting the door into the lower door hinge pin, then
❷ ❷
pressing
down and inserting the upper door hinge pin.
Repeat with the right cabinet door assembly.
STEP 13
Use four (4) M6x12 screws [a.] to attach one (1) garbage bag
bracket (L) and one (1) garbage bag bracket (R) to the right side of
the cabinet.
STEP 14
❶ ❶
Thread two (2) M4x22 shoulder bolts [d.] into the lower
holes of the garbage bag brackets.
❷❷
Use two (2) M4x22 shoulder bolts [d.] to attach the garbage bag
holder to the garbage bag brackets.
[a.] × 4
L
R
❶
❷
❶
❷
❶
❷
