1
Oven body (1 piece)
2
Oven lid
(1 piece)
3
Oven door
(1 piece)
4
Pizza stones
(2 pieces)
5
Power cord
(1 piece)
6
Motor (1 piece)
7
Rotating shaft
(1 piece)
8
Bronze sleeve
(1 piece)
9
Bearing bracket
(1 piece)
10
Turntable
(1 piece)
11
Feet (4 pieces)
12
Legs (4 pieces)
13
Side handles
(2 pieces)
14
Handle stando
(L) (2 pieces)
15
Handle stando
(R) (2 pieces)
16
Fixing plates
(4 pieces)
17
Front cart panel
(1 piece)
18
Cart side panels
(2 pieces)
19
Cart frames
(2 pieces)
20
Front logo panel
(1 piece)
21
Orange back-
ground panel (1 piece)
22
Rear cart panel
(1 piece)
23
Cart base
(1 piece)
24
Caster wheels
(4 pieces)
25
Wheel brackets
(4 pieces)
[a.] M6x14 screws
(70 pieces)
[b.] M6x14 coun-
tersunk screws
(3 pieces)
[c.] M4x12 screws
(5 pieces)
[d.] M6 nuts (3 pieces)

