1.SD/MMC input 2. USB Input 3. Play/Pause folder select 4. Mode Select 5. Track repeat 6. Prev. Track 7. Next Track 8. EQ
9. XLR MIC In
10. ¼” MIC input 11. Echo effect level
12. MIC gain level
13. XLR MIC in 15. Echo effect level
14. ¼” MIC input 16. MIC gain level
17. 5 band EQ 18. Echo effect control
19. RCA stereo line in 20. RCA Stereo Line out
21. MP3/line in selector 22. Line in/mp3 gain level
23. Master Volume Control
24. Amplifier heat sink
25. 8ohm Speaker output 26. Voltage input selector
27. Master power switch
28. AC power input
