Black+Decker BFSD116B - Set up & Use; Parts & Features

Page 6
ENGLISH
PARTS & FEATURES
SET UP & USE
Spinner
Loosen
Tighten
1
2 7
3
4
5 6
8 9
10
13
11
14
15
16
17
18
19
20
12
1. Front Grill
2. Plastic Ring with Buckle
3. Spinner
4. Small Blade
5. Large Blade
6. Plastic Nut
7. Rear Grill
8. Motor Shaft
9. Motor Housing
10. Adjustable Tilt
11. Unit Head
12. Control Panel
13. Thumb Screw
14. Adjustable Pole
15. Height Adjustment Ring
16. Extension Pole
17. Base
18. Washer
19. 7-Shaped Bolt
20. Remote
