Black+Decker BXPW1300E - Page 14

ENGLISH
14
(Original instructions)
Power 1500W (1.5 kW)
Working Flow 5 l/min
Max water Flow 6.5 l/min
Pressure 8 MPa (80 bar)
Maximum Pressure 12 MPa (120 bar)
PSI 1740
T° Input 50 ºC
Maximum Input Pressure 1 MPa
Repulsive Force of the Gun
to the Maximum Pressure 10.5 N
Motor Insulation Class F
Motor Protection IPX5
Sound Level K=3 dB(A):
L
PA
(EN 60704-1) 75.8 dB(A)
L
WA
(EN 60704-1) 90 dB(A)
Unit Vibrations (K=1 m/s
2
) ‹2.5 m/s
2
Weight 4.9 kg
BXPW1500E
220-240 V~ 50/60 Hz
Power 1700W (1.7 kW)
Working Flow 5.3 l/min
Max water Flow 7 l/min
Pressure 9 MPa (90 bar)
Maximum Pressure 13 MPa (130 bar)
PSI 1885
T° Input 50 ºC
Maximum Input Pressure 1 MPa
Repulsive Force of the Gun
to the Maximum Pressure 11.9 N
Motor Insulation Class F
Motor Protection IPX5
Sound Level K=3 dB(A):
L
PA
(EN 60704-1) 78.8 dB(A)
L
WA
(EN 60704-1) 93 dB(A)
Unit Vibrations (K=1 m/s
2
) ‹2.5 m/s
2
Weight 6.7 kg
BXPW1700E
220-240 V~ 50/60 Hz
Power 1600W (1.6 kW)
Working Flow 5.3 l/min
Max water Flow 7 l/min
Pressure 8.5 MPa (85 bar)
Maximum Pressure 12.5 MPa (125 bar)
PSI 1813
T° Input 50 ºC
Maximum Input Pressure 1 MPa
Repulsive Force of the Gun
to the Maximum Pressure 11.6 N
Motor Insulation Class F
Motor Protection IPX5
Sound Level K=3 dB(A):
L
PA
(EN 60704-1) 77.6 dB(A)
L
WA
(EN 60704-1) 92 dB(A)
Unit Vibrations (K=1 m/s
2
) ‹2.5 m/s
2
Weight 5.5 kg
BXPW1600E
220-240 V~ 50/60 Hz
Power 1800W (1.8 kW)
Working Flow 5.5 l/min
Max water Flow 7.3 l/min
Pressure 10 MPa (100 bar)
Maximum Pressure 13.5 MPa (135 bar)
PSI 1958
T° Input 50 ºC
Maximum Input Pressure 1 MPa
Repulsive Force of the Gun
to the Maximum Pressure 13 N
Motor Insulation Class F
Motor Protection IPX5
Sound Level K=3 dB(A):
L
PA
(EN 60704-1) 75.8 dB(A)
L
WA
(EN 60704-1) 93 dB(A)
Unit Vibrations (K=1 m/s
2
) ‹2.5 m/s
2
Weight 7.6 kg
BXPW1800E
220-240 V~ 50/60 Hz
