Black+Decker BXPW1300E - Page 6

6
ENGLISH
(Original instructions)
Note: The diagrams are for reference, the product may change in appearance or specifications without notice.
Volt
L1
S
N
Z1
1~
M
T
S1
NCNOC
S = Switch
Z1 = Capacitor supressor
T = Thermal protector
M = Motor
S1 = Pressure switch
220-240 V~ 50/60 Hz
2 x 2,5mm
2
10m Max
FIG. F
BXPW1700E
BXPW1800E
