Product may vary slightly from what is illustrated.
1. Empty dust bin release
2. † Cyclonic filter (Part # VCBD8090-07)
3. Hose connector end
4. † Flexible swivel hose (Part # VCBD8090-04)
5. † Removable dust collector (Part #VCBD8090-08)
6. Lid latch for HEPA grade intake filter access
7. Carr ying handle
8. Dust collector compartment release button
9. † HEPA grade intake filter (Part # VCBD8090-05) (not shown)
10. † HEPA exhaust filter (Part # VCBD8090-06) (not shown)
11. On/Off button
12. Variable Speed Control (not shown)
13. † Scratch-resistant rubber wheels (Part # VCBD8090-09)
14. † Vacuum cleaner with 360-degree steering (Part # VCBD8090-01) (not shown)
15. Max fill line
16. † Combination floor brush (Part # VCBD8090-02)
17. Combination floor brush adjuster
18. Entension Tubes (Part # VCBD8090-03)
19. Retractable cord push button (not shown)
20. † Crevice tool (Part # VCBD8090-10)
21. † Dust brush (Part # VCBD8090-11)
Note: † indicates consumer replaceable/removable parts
3
8
5
4
13
1
11
7
6
2
18
16
17
