Procedure
Take the following steps, observing all cautions and warnings in the “Important Safety
Instructions” section at the front of this manual.
1. Turn off vehicle ignition and all accessories (radio, A/C, lights, connected cell
phone chargers, etc.). Place vehicle in “park” and set the emergency brake.
2. Make sure the Jump-Starter Power Switch is turned to off.
3. Remove jumper clamps from clamp tabs. Connect the red clamp first, then the
black clamp.
4. Procedure for jump-starting a NEGATIVE GROUNDED SYSTEM (negative battery
terminal is connected to chassis) (MOST COMMON)
4a. Connect positive (+) red clamp to vehicle battery’s positive terminal.
4b. Connect negative (–) black clamp to chassis or a solid, non-moving, metal
vehicle component or body part. Never clamp directly to negative battery
terminal or moving part. Refer to the automobile owner’s manual.
5. Procedure for jump-starting POSITIVE GROUND SYSTEMS
Note: In the rare event that the vehicle to be started has a Positive Grounded System
(positive battery terminal is connected to chassis), replace steps 4a and 4b
above with steps 5a and 5b, then proceed to step 6.
5a. Connect negative (–) black clamp to vehicle battery’s negative terminal.
5b. Connect positive (+) red clamp to vehicle chassis or a solid, non-moving,
metal vehicle component or body part. Never clamp directly to Positive
battery terminal or moving part. Refer to the automobile owner’s manual.
6. When clamps are connected properly, turn the Jump-Starter Power Switch to ON.
7. Turn ON the ignition and crank the engine in 5-6 second bursts until engine starts.
8. Turn the Jump-Starter Power Switch back to the OFF position.
9. Disconnect the negative (–) engine or chassis clamp first, then disconnect the
positive (+) battery clamp.
WARNING – TO REDUCE THE RISK OF INJURY OR PROPERTY DAMAGE:
• Follow all safety instructions found in the “Specific Safety Instructions for Jump
Starters” section of this instruction manual.
• This power system is to be used ONLY on vehicles with 12-volt DC battery systems.
• Never touch red and black clamps together — this can cause dangerous sparks,
power arcing, and/or explosion.
• After use, turn the Jump-Starter Power Switch off.
CAUTION – TO REDUCE THE RISK OF PROPERTY DAMAGE:
• Vehicles that have on-board computerized systems may be damaged if vehicle
battery is jump-started. Before jump-starting this type of vehicle, read the vehicle
manual to confirm that external-starting assistance is advised.
• Excessive engine cranking can damage the vehicle‘s starter motor. If the engine
fails to start after the recommended number of attempts, discontinue jump-start
procedure and look for other problems that need to be corrected.
• If the connections to the battery’s positive and negative terminals are incorrect, the
Reverse Polarity Indicator will light and the unit will sound a continuous alarm until
the clamps are disconnected. Disconnect clamps and reconnect to battery with
correct polarity.
• If vehicle fails to start, turn off the ignition, turn off the Jump-Starter Power Switch,
disconnect the jump-start system’s leads and contact a qualified technician to
investigate why the engine did not start.
• Recharge this unit fully after each use.
PORTABLE COMPRESSOR
The built-in 12 volt DC compressor is the ultimate compressor for all vehicle tires,
trailer tires and recreational inflatables. The compressor hose with Sure Fit
®
nozzle
connector is stored in a storage compartment on the back of the unit. The On/Off
Switch is located on the rear of the unit under the air pressure gauge. The compressor
can operate long enough to fill up to 3 average sized tires before the battery must
be recharged.
The compressor may be used by removing the air hose from the storage compartment
and if required, fitting an appropriate nozzle to the air hose. Return hose to the storage
compartment after use.
WARNING – BURST HAZARD
• The compressor is capable of inflating up to 120 pounds per square inch (psi)
pressure. To avoid over-inflation, carefully follow instructions on articles to be
inflated. Never exceed recommended pressures. Bursting articles can cause
serious injury.
• Always check pressure with the pressure gauge.
• Never leave the compressor unattended while in use.
CAUTION – TO REDUCE THE RISK OF PROPERTY DAMAGE:
Do not operate compressor continuously for extended periods of time (approximately
10 minutes, depending on ambient temperatures), as it may overheat. In such event,
compressor will automatically shut down. Immediately turn OFF the Compressor
Power Switch. Restart after a cooling down period of approximately 30 minutes.
INFLATING TIRES OR PRODUCTS WITH VALVE STEMS
1. Screw the Sure Fit
®
nozzle connector onto the valve stem. Do not overtighten.
2. Turn on the compressor power switch.
3. Check pressure with the pressure gauge.
4. When desired pressure is reached, turn off the compressor power switch.
5. Unscrew and remove the Sure Fit
®
nozzle connector from the valve stem.
6. Allow the unit to cool before storing away.
7. Store the compressor hose and nozzle connector in the storage compartment.
INFLATING OTHER INFLATABLES WITHOUT VALVE STEMS
Inflation of other items requires use of one of the nozzle adapters.
1. Select the appropriate nozzle adapter (i.e, needle).
2. Screw the adapter into the Sure Fit
®
nozzle connector. Do not overtighten.
3. Insert the adapter into item to be inflated.
4. Turn on the compressor power switch — inflate to desired pressure or fullness.
Important! Small items such as volleyballs, footballs, etc. inflate very rapidly. Do
not over-inflate.
5. When desired pressure is reached, turn off the compressor power switch.
6. Disconnect the adapter from the inflated item.
7. Unscrew and remove the adapter from the Sure Fit
®
nozzle connector.
8. Allow the unit to cool before storing away.
9. Store the compressor hose, nozzle connector and adapter in the storage compartment.
Recharge this unit fully after each use.
WARNING – TO REDUCE THE RISK OF INJURY OR PROPERTY DAMAGE: Follow
all safety instructions found in this instruction manual.
120 VOLT AC PORTABLE POWER SUPPLY AND
USB CHARGING PORTS
This unit has a built-in Power Inverter that provides up to 200 watts of AC power. This
inverter is an electronic device that converts low voltage DC (direct current) electricity
from a battery to 120 volts AC (alternating current) household power. It converts
power in two stages. The first stage is a DC-to-DC conversion process that raises the
low voltage DC at the inverter input to 145 volts DC. The second stage is a MOSFET
bridge stage that converts the high voltage DC into 120 volts, 60 Hz AC.
Power Inverter Output Waveform
The AC output waveform of this inverter is known as a modified sine wave. It is a stepped
waveform that has characteristics similar to the sine wave shape of utility power. This
type of waveform is suitable for most AC loads, including linear and switching power
supplies used in electronic equipment, transformers, and small motors.
Rated Versus Actual Current Draw of Equipment
Most electrical tools, appliances, electronic devices and audio/visual equipment have
labels that indicate the power consumption in amps or watts. Be sure that the power
consumption of the item to be operated is below 200 watts. If the power consumption
is rated in amps AC, simply multiply by the AC volts (120) to determine the wattage.
Resistive loads are the easiest for the inverter to run; however, it will not run larger
resistive loads (such as electric stoves and heaters), which require far more wattage
than the inverter can deliver. Inductive loads (such as TVs and stereos) require more
current to operate than do resistive loads of the same wattage rating.
CAUTION: Rechargeable Devices
• Certain rechargeable devices are designed to be charged by plugging them directly
into an AC receptacle. These devices may damage the inverter or the charging
circuit.
• When using a rechargeable device, monitor its temperature for the initial ten
minutes of use to determine if it produces excessive heat.
• If excessive heat is produced, this indicates the device should not be used with
this inverter.
• This problem does not occur with most of the battery-operated equipment. Most
of these devices use a separate charger or transformer that is plugged into an AC
receptacle.
• The inverter is capable of running most chargers and transformers.
Protective Features
The inverter monitors the following conditions:
Low internal battery voltage: The inverter will automatically shut down when the
battery voltage drops too low, as this can harm the battery.
High internal battery voltage: The inverter will automatically shut down when the
battery voltage is too high, as this can harm the unit.
Thermal shutdown protection: The inverter will automatically shut down when the unit
becomes overheated.
Overload/short circuit protection: The inverter will automatically shut down when an
overload or short circuit occurs.
IMPORTANT NOTES: The Inverter Power/Fault Indicator is located inside the
Translucent Inverter/USB Power Button. It will light solid when the unit is functioning
properly and flash to indicate that one of the above fault conditions is present before
automatic shutdown occurs.
Notes: This inverter’s USB charging ports do not support data communication. The ports
only provide a total of 2.1A (5V each) DC power to external USB-powered devices.
If a fault condition occurs in the 120V AC outlet OR any of the USB Charging Ports,
the Inverter Power/Fault Indicator will flash and both the 120V AC outlet and the
USB charging ports will shut down automatically.
Some USB-powered household electronics may not operate with these USB power
ports. Check the manual of the corresponding electronic device to confirm that it
can be used with this type of USB power port.
Not all mobile phones are provided with a charging cable. They are normally data
cables which are not supported by this device – please check with your mobile
phone manufacturer for the correct charging cable.
Some laptop computers may not operate with this inverter.
The inverter will not operate appliances and equipment that generate heat, such as
hair dryers, electric blankets, microwave ovens and toasters.
Make sure the Translucent Inverter/USB Power Button is pressed to turn the inverter
off (the Inverter Power/Fault Indicator is not lit) when the unit is not in use, being
recharged or stored.
Recharge this unit fully after each use.
Using the 120 Volt AC Outlet and USB Charging Ports
1. Press the Translucent Inverter/USB Power Button to turn on the 120 Volt AC
Outlet and the two USB Power Ports. The Inverter Power/Fault Indicator will light
solid to indicate the 120 Volt AC Outlet and the two USB Power Ports are ready to
use.
2. Plug the 120 volt AC appliance into the 120 Volt AC Outlet and/or plug the USB-
powered devices into one of the inverter’s USB Power Ports and operate normally.
• Stay clear of fan blades, belts, pulleys, and other parts that can cause injury to persons.
• Remove personal metal items such as rings, bracelets, necklaces and watches when
working with a lead acid battery. A
lead acid battery can produce a short circuit current high enough to weld a ring, or
similar metal object, to skin, causing a severe burn.
• Do not wear vinyl clothing when jump-starting a vehicle. Friction can cause
dangerous static-electrical sparks.
• Be extra careful to avoid dropping a metal tool onto the battery. It might spark or
short-circuit the battery or another electrical part and could cause an explosion.
• Jump-start procedures should only be performed in a safe, dry, well-ventilated area.
• Always store battery clamps when not in use. Never touch battery clamps together.
This can cause dangerous sparks, power arcing and/or explosion.
• When using this unit close to the vehicle’s battery and engine, stand the unit on a
flat, stable surface, and be sure to keep all clamps, cords, clothing and body parts
away from moving vehicle parts.
• Never allow red and black clamps to touch each other or another common metal
conductor — this could cause damage to the unit and/or create a sparking/
explosion hazard.
• Make sure to connect the clamps with correct polarity. Damage caused by improper
connection is not covered by the Warranty.
• Do not expose battery to fire or intense heat since it may explode. Before disposing
of the battery, protect exposed terminals with heavy-duty electrical tape to prevent
shorting (shorting can result in injury or fire).
• Place this unit as far away from the battery as cables permit.
• Never allow battery acid to come in contact with this unit.
• Do not operate this unit in a closed area or restrict ventilation in any way.
• This system is designed to be used only on vehicles with a 12 volt DC battery
system. Do not connect to a 6 volt or 24 volt battery system.
• This system is not designed to be used as a replacement for a vehicular battery. Do
not attempt to operate a vehicle that does not have a battery installed.
• Excessive engine cranking can damage a vehicle’s starter motor. If the engine
fails to start after the recommended number of attempts, discontinue jump-start
procedures and look for other problems that may need to be corrected.
• Do not use this jump starter on a watercraft. It is not qualified for marine
applications.
• Although this unit contains a non-spillable battery, it is recommended that unit be
kept upright during storage, use and recharging. To avoid possible damage that
may shorten the unit’s working life, protect it from direct sunlight, direct heat and/
or moisture.
SPECIFIC SAFETY INSTRUCTIONS FOR INVERTERS
WARNING – TO REDUCE THE RISK OF ELECTRIC SHOCK:
• Do not connect to AC distribution wiring.
• Do not make any electrical connections or disconnections in areas designated as
IGNITION PROTECTED. This inverter is NOT approved for ignition protected areas.
• Never immerse the unit in water or any other liquid, or use when wet.
• Do not insert foreign objects into the unit’s AC outlets.
WARNING – TO REDUCE THE RISK OF FIRE:
• Do not operate near flammable materials, fumes or gases.
• Do not expose to extreme heat or flames.
CAUTION – TO REDUCE THE RISK OF INJURY OR PROPERTY DAMAGE:
• Disconnect appliance plug from inverter outlet before attempting any repairs to
the appliance.
• When an appliance plugged into this unit is used outdoors, use only extension
cords intended for use outdoors and so marked.
• Do not attempt to connect the inverter while operating your vehicle. Not paying
attention to the road may result in a serious accident.
• Always use the inverter where there is adequate ventilation.
• Always turn the inverter off when not in use.
• Keep in mind that this inverter will not operate high wattage appliances or equipment
that produce heat, such as hair dryers, microwave ovens and toasters.
• Do not use this inverter with medical devices. It is not tested for medical
applications.
• Some laptop computers may not operate with this inverter.
• Operate inverter only as described in this Instruction Manual.
CAUTION: RECHARGEABLE DEVICES
• Certain rechargeable devices are designed to be charged by plugging them directly
into an AC receptacle. These devices may damage the inverter or the charging circuit.
• When using a rechargeable device, monitor its temperature for the initial ten
minutes of use to determine if it produces excessive heat.
• If excessive heat is produced, this indicates the device should not be used with
this inverter.
• This problem does not occur with most of the battery-operated equipment. Most
of these devices use a separate charger or transformer that is plugged into an AC
receptacle.
• The inverter is capable of running most chargers and transformers.
SPECIFIC SAFETY INSTRUCTIONS FOR THE USB PORTS
• Do not insert foreign objects into the USB Ports.
• Do not attach USB hubs or more than one personal electronic device to each USB
Port.
• Do not use this unit to operate appliances that require more than 2.1 amps in total
to operate from the USB Ports.
• Some household USB-powered electronics will not operate with this unit.
SPECIFIC SAFETY INSTRUCTIONS FOR COMPRESSORS
CAUTION – TO REDUCE THE RISK OF INJURY OR PROPERTY DAMAGE: Never
leave the compressor unattended while in use.
WARNING – BURST HAZARD: Bursting articles can cause serious injury.
• Carefully follow instructions on articles to be inflated.
• Never exceed the recommended pressure listed in instructions on articles to be
inflated. If no pressure is given, contact article manufacturer before inflating.
• Monitor the pressure at all times on the pressure gage.
CAUTION – TO REDUCE THE RISK OF PROPERTY DAMAGE: Do not operate
compressor continuously for longer than approximately 10 minutes, depending on
ambient temperatures, as it may overheat.
FIRST AID
When working with lead acid batteries, always make sure immediate assistance is
available in case of accident or emergency.
Always have protective eyewear when using this product: contact with battery acid
may cause blindness and/or severe burns. Be aware of first aid procedures in case of
accidental contact with battery acid.
Have plenty of fresh water and soap nearby in case battery acid contacts skin.
• Skin: If battery acid comes in contact with skin, rinse immediately with water, then
wash thoroughly with soap and water. If redness, pain, or irritation occurs, seek
immediate medical attention.
• Eyes: If battery acid comes in contact with eyes, flush eyes immediately, for a
minimum of 15 minutes and seek immediate medical attention.
SAVE THESE
INSTRUCTIONS
WARNING: TO REDUCE THE RISK OF INJURY:
Follow these instructions and those published by the battery manufacturer and
manufacturer of any equipment you intend to use with this unit. Review cautionary
markings on these products and on engine.
INTRODUCTION
Thank you for choosing the Black & Decker Jump-Starter with Compressor. Please
read this guide carefully before use to ensure optimum performance and avoid
damage to the unit or items that you are using it with.
CHARGING/RECHARGING
Lead-acid batteries require routine maintenance to ensure a full charge and long
battery life. All batteries lose energy from self-discharge over time and more rapidly
at higher temperatures. Therefore, batteries need periodic charging to replace energy
lost through self-discharge. When the unit is not in frequent use, manufacturer
recommends the battery be recharged at least every 30 days.
Notes: This unit is delivered in a partially charged state – you must fully charge it upon
purchase and before using it for the first time. Initial AC charge should be for 24
hours.
Recharging battery after each use will prolong battery life; frequent heavy
discharges between recharges and/or overcharging will reduce battery life. The
battery can be recharged using the Built-In 120 Volt AC Charger.
Make sure all other unit functions are turned off during recharging, as this can slow
the recharging process.
IMPORTANT: If you know the unit is discharged, but the battery status LEDs
illuminate as if fully charged when connected to a charging power source, this may
be due to the internal battery having a high impedance. The manufacturer suggests
leaving the unit on charge for a period of 24-48 hours before use.
CAUTION – RISK OF PROPERTY DAMAGE: Failure to keep the battery charged will
cause permanent damage and result in poor jump-starting performance.
Charging/Recharging the Jump-Starter Using the 120 Volt AC
Charger and a Standard Household Extension Cord
(not included)
1. Lift the AC adapter cover located on the back of the unit and connect an extension
cord to the unit. Plug the other end of the cord into a standard 120-volt AC wall
outlet.
2. Charge until the green Battery Status LED Indicator lights solid or flashes.
3. Disconnect the extension cord.
JUMP-STARTER
This unit is equipped with a jump starter power switch that allows energy to flow only
when proper connections are made to battery and frame.
a) For negative-grounded systems, connect the positive (red) clamp to the
positive ungrounded battery post and the negative (black) clamp to the vehicle
chassis or engine block away from the battery. Do not connect the clamp to the
carburetor, fuel lines or sheet-metal body parts. Connect to a heavy gage metal
part of the frame or engine block.
b) For positive-grounded systems, connect the negative (black) clamp to the
negative ungrounded battery post and the positive (red) clamp to the vehicle
chassis or engine block away from the battery. Do not connect the clamp to the
carburetor, fuel lines or sheet-metal body parts. Connect to a heavy gage metal
part of the frame or engine block.
IMPORTANT: Make sure the Compressor Power Button has been turned off before
attempting to use the unit as a Jump Starter.
To Next Page
Loading...
