Black+Decker NVC220WC - Installation; Assembly; Use; Charging the Battery via Charger Base

6
ENGLISH
This tool is double insulated;
therefore no earth wire is
required. Always check that the
power supply corresponds to
the voltage on the rating plate.
The charging base is intended
for indoor use only.
Labels on appliance
The following symbols appear on this appliance along with the
date code:
NVC115JL/NVC115W/NVC115WA/
WDC115WA Only use with charger
SSC-040015**/ S003BD*0500015
NVC215W/NVC215WA/NVC220WC/
WDC215WA Only use with charger
SSC-080015**/ S003BD*0800015
Features
This tool includes some or all of the following features.
1. On/off switch
2. Bowl release button
3. Dust bowl
4. Charger base (NVC115W, NVC115WA, NVC215W,
NVC215WA, NVC220WC, WDC115WA, WDC215WA
units only).
4a. Charger jack plug (NVC115JL unit only).
5. Retractable crevice tool (NVC215W, NVC215WA and
NVC220WC Only)
6. Brush tool (NVC115WA, NVC215WA, NVC220WC,
WDC115WA and WDC215WA Only)
7. Crevice tool (NVC115WA, WDC115WA and WDC215WA
Only)
8. Squeegee (WDC115WA and WDC215WA units Only)
Fig. A
10. Dry pick up cloth lter (NVC units Only)
11. Pre-lter (NVC units Only)
12. Wet/Dry foam insert (WDC units Only)
13. Wet/Dry deector (WDC units Only)
Installation
Wall Mounting (NVC115W, NVC115WA, NVC215W,
NVC215WA, NVC220WC, WDC115WA, WDC215WA units
only). (g. B)
The product can be attached to a wall to provide a convenient
storage and charging point for the appliance.
When xing to a wall, make sure that the xing method is
suitable for the wall type and is appropriate to the weight of
the appliance.
u Mark the location of the screw holes (within reach of an
electrical outlet for charging the vac while it is on the wall
bracket).
u Fix the mounting bracket to the wall using appropriate
screws and plugs for the type of wall and weight of the
appliance.
u Hang the appliance on the wall by placing the opening on
the base of the vac over the hook in the wall mount charg-
ing bracket.
Assembly
Accessories (g. C)
These models may be supplied with some of the following
accessories:
u A squeege tool (8) for wet use on hard surfaces.
u A brush tool (6) for furniture and stairs.
u A crevice tool (7) for conned spaces.
Fitting (Fig. C)
u Insert the appropriate accessory into the front of the appli-
ance. Make sure that the accessory is pushed fully in.
Retractable crevice tool (NVC215W, NVC215WA and
NVC220WC units only) (Fig. D)
u Extend the crevice tool (5) as shown in gure D, until it
clicks in place.
u To retract the crevice tool, push down on the button (5a)
and slide back into the dust bowl (3) as shown in gure D.
Use
u Before rst use, the battery must be charged for at least
24 hours.
Warning! Before charging, be sure to empty all liquid contents
and dry thoroughly, to avoid damage to your appliance.
Charging the battery via charger base (NVC115W,
NVC115WA, NVC215W, NVC215WA, NVC220WC,
WDC115WA, WDC215WA units only) (Fig. B)
u Make sure that the appliance is switched off. The battery
will not be charged with the on/off switch (1) pressed.
u Place the appliance on the charging bracket (4).
u Plug in the charger. Switch on at the mains.
u Leave the appliance to charge for at least 21 hours.
While charging, the charger may become warm. This is
normal and does not indicate a problem. The appliance can
be left connected to the charger indenitely.
Warning! Do not charge the battery at ambient temperatures
below 10 °C or above 40 °C.
SSC-040015**/
S003BD*0500015
S003AQ 15
SSC-080015**/
S003BD*0800015
S003AQ 15
#
