INTERNATIONAL WARRANTY
Terms and Conditions
1. BLACKPOINT warrants the operation of this product to
be free from any manufacturing and/or material defect for a
period of 6 months from the date of purchase by the user.
2. This warranty is limited to the repair and/or replacement
of this product, according to our own criterion, free of
charge within the stipulated term and it does not extend to
consequential or incidental damages to other products that
may be used with this unit.
3. The warranty shall be voided in the following cases: a)
repair or attempt to repair by third parties not authorized
by the company. b) in case of performing any type of cut
in connection cables, plugs, connectors, or other adapters
different from the original ones provided by the company.
4. To make this warranty effective, you shall contact the
Authorized Service Center of your country and they shall carry
out the pertinent procedure. In order to start the necessary
procedure to get said warranty, you shall hand in the Original
Purchase Invoice where the purchase date, dealer name and
product identication shall be stated clearly.
5. Transportation, freight, stay and/or insurance expenses, if
any, are not covered by this warranty.
REPAIR SERVICE
To ask for customer service please call 0810-888-7262.
USER MANUAL
X32 CAR AUDIO
User’s Guide
Thank you for purchasing X32 Blackpoint’s Car Audio.
Please read the manual carefully before operating.
FEATURES
Wireless BT connection
LCD display
FM Radio
USB/SD
Digital clock
AUX-in
Charge up mobile
10Wx4 max output
SPECIFICATIONS
Detachable
12p connector
Size:17.8 x5x8.5cm
FRONT PANEL
MAIN FUNCTION:
1.SD/MMC/USB/MP3 compatible play system
2. Support big capability mobile hard disk play function
3.Total gure radio tuning system
4.Electronic volume control
5.Real-time clock function
6.LED/LCD display
7.High power output
8.RCA line out RCA
BASIC OPERATIONS:
1.
/MUT: Long press this button to power on and mute,
short press to power off.
2. MOD: press this button to choose different mode. FM—
USB—SD-BT.
3.
:During radio mode, brief press this button to auto-
search stations forward, long press to manual search station
forward. During playback mode., short press to play previous
song, long press to go fast forward.In BT station, brief press
to answer the phone.
www.blackpoint.life
WARNING!
To prevent re or electric shock, do not expose this
appliance to rain or moisture.
Do not remove the cover (on the back), there are no
internal parts that can be repaired by the user. Consult
service to qualied service personnel
4.
: During radio mode, brief press this button to auto-
search stations backward, long press to manual search
station backward. During playback mode., brief press to play
previous song, long pressto go fast backward.In BT station,
brief press to hang up the phone.
5. CLK: Brief press to display clock, long press to enter clock
setting, using volume knob to adjust clock setting.
6.BND: Brief press to switch band range, long press to store
stations.
7. 1/
: During radio mode, brief press to choose number 1
preset stations. During playback mode, brief press to pause,
press again to play.
8.2/INT: During radio mode, brief press to choose number
2 preset station. During playback mode, press to brief play
each song for rst 10 second.
9.3/RPT: During radio mode, brief press to choose number 3
preset station. During playback mode, press to repeat.
10.4/RDM: During radio mode, brief press to choose number
4 preset station. During playback mode, press to random play.
11.5/10-: During radio mode, brief press to choose number
5 preset station. During playback mode, press to jump to
previous 10 songs.
12.6/10+: During radio mode, brief press to choose number 6
preset station. During playback mode, press to next 10 song.
13.VOL: Volume control. During playback mode, brief press
to activate EQ setting, rotate volume knob to choose each
preset EQ.
INSTALLATION AND REMOVING
This unit is designed to prevent the thieves, please x
carefully follow the process of installation.
INSTALLATION
Press the curving lock sheath
of the unit, put the sheath
into dashboard, and then
push the unit into the sheath
till it was locked. But sure
that the unit is installed in an
appropriate situation, so that
the drivers can control the
car normally and prevent the
car from braking suddenly the
passenger will be hurt.
NOTICE
1.Before the unit installation, please check the power
output and check that if the unit works normally.
2.Please use the accessory we offered only, or else beget
needless breakage. If you need to alter the fabric of the car,
please call your seller.
REMOVING
Put the keys given into the
keyholes on the two sides
of the unit, until the lock is
unlocked, then remove the
unit with the keys.
MAINTENANCE
1.Make sure your car battery is a 12 volt.
2.Please check the installation and wire if correct, after
connecting all the,wire, connect the power supply to
the positive of the battery.
3.Please use cramp or tape to make the head of wire is
isolated from the metal of car.
4.Please x all the wire to avoid touch any offset
objects.
CERTIFICATE OF CONFORMITY
PERFORMANCE INDEX
FM
Turning range 87.5MHZ~108MHZ
Antenna terminal connect antenna linker
Middle frequency 10.7MHZ
Practicality sensitivity <=22db
Choice >=45db(400KHZ)
Signal-to-noise radio >=50dB
Band distortion(1khz) <=5%
Separation(1khz) >=22db
Frequency response (100Hz~10kHz)±6dB
POWER AMPLIFFIER SECTION:
Output speacker output
Speaker impedance 4
Maximum power output (10Wx4)
Power supply voltage 12VDc battery
(Negative connect ground sire)
x32
