14
SERVICING
TYPE OF TYPE OF SINGLE - PHASE
HOT PLATE CABLE POWER SUPPLY
CABLE TYPES AND SECTIONS
ATTENTION!!!
If the power supply cable is replaced, the installer should leave the ground wire (B) longer than the phase
conductors (fig. 16) and comply with the recommendations given in paragraph 6.
FIG. 16
H05 RR - F Section 3 X 0.75 mm
2
Gas hot plate
If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly
qualified person i n order to avoid a hazard.
WARNING!
In the envelope you will find the duplicate parts of the rating plate,
which must be applied in the cabinet near the hob to be displayed
easily in case of maintenance.
WARNING: MAINTENANCE MUST ONLY BE
PERFORMED BY AUTHORIZED PERSONS.
