26
Drill two holes in the
wall for each bracket
according to the g. 2
and x the bracket.
Hose Restraint Chain
The installer must t a chain, no more than 80% of the hose length to
ensure that there is no strain on the hose when the cooker is pulled
forward. Attach one end of the chain as close as possible to the gas
inlet on the cooker and the other end as close as possible to the gas
outlet on the wall. Suitable chain and ttings are to be supplied by the
installer.
Mark it the same dis-
tance, (X) on back wall.
IMPORTANT: After tting the stablising brackets and pushing the cooker
into position, check that the cooker does not tilt forward or sideways
Push back the cooker
against the wall.
INSTRUCTIONS FOR THE INSTALLER
