INSTRUCTIONS FOR THE INSTALLER
GAS CONVERSIONS
REPLACING THE INJECTORS
Our burners can be adapted to different
types of gas by simply installing the injectors
suitable for the gas you want to use. To help
the installer, the table (see TECHNICAL
FEATURES paragraph) gives the burner
nominal heat input, injector diameter and
operating pressure of the different gas types.
Comply with the following instructions:
Injector replacement - Hob burners.
To change the injectors on the hob, remove
the burner cup and head and with a 7 mm Ø
After having replaced the injectors, it will
be necessary to proceed with burner
adjustment as explained in the previous
paragraphs.
20
21
REPLACING THE ELECTRICAL
COMPONENT
removed in order to change the electrical
heating elements, spit motor, terminal
board and power cable.
If you have to change the power cable
(see TECHNICAL FEATURES paragraph),
always keep the earth wire longer than the
phase wires and, in addition, follow all the
instructions given in the “ELECTRICAL
CONNECTION” paragraph.
instructions REPLACING THE OVEN
LAMP paragraph.
, use a
screwdriver to push the clamp tips (M) and
pull the lamp holder out towards the inside
of the oven.
generator and the spark electrodes, the
work top has to be removed as indicated
in the paragraph «REPLACING THE
TAPS».
the thermostat, the commutator and the
warning lights, remove the front panel by
lock it to the front frame.
