8
A








B
DESCRIPTION OF THE APPLIANCE
DESCRIPTION OF THE CONTROLS
HOB GAS BURNER KNOB (A)
By rotating the knob in an anticlockwise
FKTGEVKQPVJGHQNNQYKPIU[ODQNUCRRGCT
= Closed position
= “Full on” position
= “Reduced rate or Low” position
OVEN ELECTRIC THERMOSTAT KNOB
(B)
By turning the oven knob clockwise we will
ſPFVJGFKHHGTGPVQXGPVGORGTCVWTGXCNWGU
(from 50°C to Max).
OVEN FUNCTION SELECTOR KNOB (8)
(C)
By turning the knob to the right or to the left
YGYKNNſPFVJGHQNNQYKPIU[ODQNU
0 = Oven off
= Oven light on, which stays on for all
functions
= Defrost
=Traditional
= Fan Assist (Top and bottom heating
elements and fan on)
= Bottom heating element with fan
= Fan forced (Rear heating element and
fan on)
= Grill
= Fan grill

C
YELLOW WARNING LIGHT
When lit it indicates that either the electric
oven or electric grill is working. While the
oven is being used the light will switch off
when the set temperature is reached. During
baking it is normal for the yellow light to
switch on and off several times as the oven
temperature is controlled.
RED WARNING LIGHT
When lit it indicates that the electric grill
or one of the oven electric components
is on.
