20 21
Changing the forearm tipTechnical data
Parameter: Value:
Weight 445 g
Material of body Aluminum
Material of feet Carbon
Spread of legs, retracted 24.5 cm/9.5"
Spread of legs, extended 28 cm / 11"
Minimum length of the legs 18.5 cm / 7.3"
Maximum length of the legs 28.5 cm / 11.2"
Angles 0°, 45°, 90°, 135°, 180°
Rotatable +/- 10°
Stand width min. 24.5 cm / 9.5"
Stand width max. 30.5 cm / 12"
The Blaser Ultimate BiPod forearm tip must match the barrel
diameter (17 mm for Standard barrel contours, 22 mm for
Semi-Weight and Match contours, 31 mm for Ultimate Silence
contour)
Loosen the two forearm tip mounting screws using an Allen key
(size 5) and remove them with the lock washers.
