3
TECHNICAL SPECIFICATIONS
ENGINE
one cylinder; two-stroke; air-cooled
DISPLACEMENT
39,9 ccm
POWER OUTPUT
2,5 kW at 8 700 rpm
TORQUE
3,5 Nm at 6 000 rpm
CARBURETOR
Dell’Orto 14
IGNITION
Contact-less
STARTING
Manual – hand pull type
CLUTCH
Centrifugal automatic
FRAME
welded high-strength steel tubes
BRAKE
rear disk – disk diameter 119 mm ( 4,7“ )
front
light alloy 4“ - 51
WHEEL RIMS
rear
light alloy 4“ - 95
front
3,00 – 4“
TYRES
rear
3,00 – 4“
FUEL
mixture of petrol (91 octane or higher) and synthetic oil
2T (mixing ratio 50 : 1) 100 millilitres of oil to 5 litres of
petrol.
{After running in period of 5 tanks of fuel at 30 : 1}
FUEL TANK CAPACITY
1 litre ( 0,26 US gal. )
WEIGHT
29 kg ( 63,8 lb. )
WEIGHT (incl. packing)
33 kg ( 72,6 lb. )
CARRYING CAPACITY
95 kg (209 lb. )
length
1 010 mm ( 39,7“ )
width
590 mm ( 23,2“ )
DIMENSIONS
height
630 mm ( 24,8“ )
length
106,0 cm ( 41,3“ )
width
62,0 cm ( 24,4“ )
BOX PACKING
DIMENSIONS
height
56,0 cm ( 22, 04“ )
