INSTRUCTIONS (CONT.)
3. Power Supply Insert
Please refer to below image and follow instructions:
The Signal Adaptor provided (1) connects the DC Power supply (2) and the
Antenna signal cable (3) together.
(1) - Connect Adaptor into back of TV Antenna (RF) port.
(2) - Connect the DC Power Cable (2) into the DC Input Port indicated on
on the Adaptor (1).
(3) Connect the Antenna Cable from your Outdoor TV Antenna into the
Signal Adaptor (1) ANT port.
1
2
3
