TECHNICAL SPECIFICATION
Extinguishing agent: HFC-227ea
Tube diameter: 19 mm (0.75 in)
Operation temperature: 90 °C (194 °F) maximum for TxxxE models
80 °C (176 °F) maximum for TxxxES models
Activation temperature: 105 °C ± 3 °C (221 °F ± 5 °F) for TxxxE models
100 °C ± 2 °C (212 °F ± 4 °F) for TxxxES and TxxxES-E models
Activation pressure: 24 bar ± 1 bar (348 psi ± 14 psi) for TxxxE models
25 bar ± 1 bar (363 psi ± 14 psi) for TxxxES and TxxxES-E models
Minimum bending radius: 160 mm (6.30 in)
SIZING AND SELECTION
With vehicle applications please refer to our vehicle application list instore or visit www.blazecut.com
Other applications can be calculated by a simple process:
Measure the enclosures Width x Height x Depth in metres or feet and this will calculate your m
3
or ft
3
.
Note: the enclosure should be enclosed or have minimal vents. T series is not suitable for open areas.
Then refer to the chart below to select the suitable length.
T Series Standard & Pressure Switch Models (Vehicles & Enclosures)
Model*
Volume protected at
20 °C (68 °F)
Volume protected at
20 °C (68 °F)
Amount of agent
System
length
Electrical Fires**
Engine Fires**
T025E
0.09 m
3
0.09 m
3
0.05 kg ± 2 g
28 cm
(3.18 ft
3
)
(3.18 ft
3
)
(0.11 lb ± 0.07 oz)
(11.02 in)
T050E
0.18 m
3
0.14 m
3
0.10 kg ± 2 g
53 cm
(6.36 ft
3
)
(4.94 ft
3
)
(0.22 lb ± 0.07 oz)
(20.87 in)
T100E
0.46 m
3
0.35 m
3
0.25 kg ± 5 g
113 cm
(16.24 ft
3
)
(12.36 ft
3
)
(0.55 lb ± 0.17 oz)
(44.48 in)
T200E
0.91 m
3
0.69 m
3
0.50 kg ± 5 g
215 cm
(32.14 ft
3
)
(24.37 ft
3
)
(1.10 lb ± 0.17 oz)
(84.64 in)
T300E
1.37 m
3
1.04 m
3
0.75 kg ± 10 g
319 cm
(48.38 ft
3
)
(36.73 ft
3
)
(1.65 lb ± 0.35 oz)
(125.59 in)
T400E
1.82 m
3
1.39 m
3
1.00 kg ± 10 g
422 cm
(64.27 ft
3
)
(49.09 ft
3
)
(2.20 lb ± 0.35 oz)
(166.14 in)
T500E
2.28 m
3
1.73 m
3
1.25 kg ± 10 g
526 cm
(80.52 ft
3
)
(61.09 ft
3
)
(2.76 lb ± 0.35 oz)
(207.09 in)
T600E
2.73 m
3
2.08 m
3
1.50 kg ± 10 g
630 cm
(96.41 ft
3
)
(73.45 ft
3
)
(3.31 lb ± 0.35 oz)
(248.03 in)
T025ES
0.09 m
3
0.09 m
3
0.05 kg ± 2 g
35 cm
(3.18 ft
3
)
(3.18 ft
3
)
(0.11 lb ± 0.07 oz)
(13.78 in)
T050ES
0.18 m
3
0.14 m
3
0.10 kg ± 2 g
60 cm
(6.36 ft
3
)
(4.94 ft
3
)
(0.22 lb ± 0.07 oz)
(23.62 in)
T100ES
0.46 m
3
0.35 m
3
0.25 kg ± 5 g
120 cm
(16.24 ft
3
)
(12.36 ft
3
)
(0.55 lb ± 0.17 oz)
(47.24 in)
T200ES
0.91 m
3
0.69 m
3
0.50 kg ± 5 g
222 cm
(32.14 ft
3
)
(24.37 ft
3
)
(1.10 lb ± 0.17 oz)
(87.40 in)
T300ES
1.37 m
3
1.04 m
3
0.75 kg ± 10 g
326 cm
(48.38 ft
3
)
(36.73 ft
3
)
(1.65 lb ± 0.35 oz)
(128.34 in)
T400ES
1.82 m
3
1.39 m
3
1.00 kg ± 10 g
429 cm
(64.27 ft
3
)
(49.09 ft
3
)
(2.20 lb ± 0.35 oz)
(168.89 in)
T500ES
2.28 m
3
1.73 m
3
1.25 kg ± 10 g
533 cm
(80.52 ft
3
)
(61.09 ft
3
)
(2.76 lb ± 0.35 oz)
(209.84 in)
T600ES
2.73 m
3
2.08 m
3
1.50 kg ± 10 g
637 cm
(96.41 ft
3
)
(73.45 ft
3
)
(3.31 lb ± 0.35 oz)
(250.79 in)
