SECTION 7 - PREPARING FOR USE
BLEC CULTI-PACK SEDER
MODELS - CP36/CP42
Step 2.
Fitment of seeder unit to tiller.
The seeder unit is attached to the jaw bracket on the tiller via a mounting bracket (black) which has a
scraper bar attached to it. (See Photo 3).
* disconnect the mounting bracket (1) from the drawbar of the seeder by
removing the middle pin and clip.
* slide the bracket into the jaw bracket of the tiller and secure with 2
pins and clips supplied.
* tighten locking bolt (See Photo 4), No. 3. This will keep the rackets
tight on the pins.
* the scraper bar is secured to the mounting bracket by 2 bolts and nuts
(See Photo 4).
* position and tighten.
* fitted to the scraper bar are 2 serrated scrapers which are adjustable for
width and length, via the nuts and bolts. It may be necessary to adjust the scrapers.
* when adjusting, make sure a gap of 6 - 10 mm is between the cast ring roll
and scraper to allow for movement. (See Photo 5).
* position the seeder drawbar (See Photo 3) into the mounting bracket and
secure with pin and clip. Lift up the support leg and secure with pin and clip.
The seeder and tiller are now assembled.
