SECTION 9 - MAINTENANCE BLEC CULTI-PACK SEEDER
MODELS - CP36/CP42
SCRAPER PLATES
Keep the serrated scrapers adjusted up to within 6 - 10mm from the rings (See Photo 5), on both
front and rear rolls.
To adjust, slacken off rolls (See Photo 12), and slide desired position, then retighten.
DO NOT POSITION TOO CLOSE, PLEASE ALLOW FOR MOVEMENT OF RINGS
PIVOT PINS
Located on the drawer and main frame are 2 pivot bosses which require regular greasing every 8
hours. (See Photo 12).
ROLL BEARINGS
Located on each side of the roll are 2 pieces, flange bearings which are sealed - NO MAINTE-
NANCE REQUIRED.
PLEASE CARRY OUT REGULAR WASHING OF THE CAST RING ASSEMBLIES AND FRAME,
ESPECIALLY WHEN WORKING ON CLAY SOILS.
