6
Mounting and installation
Signal Processor enclosure
Mounting Bracket
4 x 12 mm
self-tapping screw (2)
4 mm spring
washer (2)
4 mm plain
washer (2)
4x 6 mm machine screw (4)
Dashboard
Please take the time to install your new Blitz Signal Processor securely, according to this
diagram, using the hardware provided.
This Half-DIN size unit can also be installed in the dash adjacent to the head unit, provided
that there is a slot available.
