Blitz HydroLift Series - Page 124

HydroLift
Technical Annex
126746 121
Control HydroLift S3 6.2 t / 7.5 t and S2 8.2
Pos.
Name
HydroLift 6.2 t
HydroLift 7.5 t
HydroLift 8.2 t
1
Operator panel
M110062
M110062
M110062
2
Operator panel
FA7964
FA7964
FA7964
3
Emergency stop key
FA7962
FA7962
FA7962
4
Raise / lower key
FA7958-22
FA7958-22
FA7958-22
5
Lowering key
FA7968
FA7968
FA7968
6
Buzzer
FA7974
FA7974
FA7974
7
Control panel
FA7965
FA7965
FA7965
8
Plugs
FA7958-9
FA7958-9
FA7958-9
9
Input board
FA7963
FA7963
FA7963
10
Main switch
118460
118460
FA7958-4
11
Cable hooks
M120189
M120189
M120189
12
Top cover
M110060
M110060
M110060
13
Doors
M120163
M120163
M120163
14
Side panel
M110100
M110100
M110100
15
Aerial connector
M130072
M130072
M130072
16
Aerial
M110151
M110151
M110151
17
Modem Assembly
M130151
M130151
M130151
18
Self-drilling screw
-
120747
19
Master switch lock
-
M120347
20
Communication cable
M130079
M130079
M130079
21
Aerial cable
M130073
M130073
M130073
22
Power supply cable
M1300076
M1300076
M1300076
23
Power cable input board
FA7982
FA7982
FA7982
24
Wiring harness key
FA7984
FA7984
FA7984
25
Power cable control board
FA7989-2
FA7989-2
FA7989-2
26
Connection cable relay 1
FA7989-3
FA7989-3
FA7989-3
27
Connection cable relay 2
FA7989-5
FA7989-5
FA7989-5
28
Connection cable potentiometer
FA7983
FA7983
FA7983
29
Connection cable coil 24 V
FA7977
FA7977
FA7977
30
Inspection glass
M130109Y
M130109Y
M130109Y
31
Lock
MS705-9
MS705-9
MS705-9
32
Hinge
RP-003-S
RP-003-S
RP-003-S
33
Earthing cable
FA7824Y
FA7824Y
FA7824Y
34
Hexagonal bolt
4187Y
4187Y
4187Y
35
Metal sheet
FA7958-3Y
FA7958-3Y
FA7958-3Y
Self-tapping screw
M130112
M130112
M130112
Charging cable EU,
118154
118154
118154
Cover Main switch
119447
119447
-
