Blitz HydroLift Series - Page 126

HydroLift
Technical Annex
126746 123
Drawbar HydroLift S3 6.2 t / 7.5 t and S2 8.2 t
Pos.
Name
Order No.
1
Hexagonal bolt
41413-BR
2
Hexagonal bolt
41483-BR
3
Hexagonal bolt
M130129
4
Washer
41520-BR
5
Hexagonal bolt
41539-BR
6
Washer
41548-BR
7
Safety nut
41563-BR
8
Safety nut
41568-BR
9
Hexagonal nut with flange
41618-BR
10
Caster mounting
M120049Y
11
Clevis bracket
M120052Y
12
Handle
M120058Y
13
Mounting plate
M120075Y
14
Spring plate
M120077Y
15
Brake
M120080Y
16
Arm left
M120084Y
17
Compression spring
M130010
18
Wheel
M130101Y
19
Bearing plate
M130019Y
20
Brakes spring
M130020Y
21
Middle bearing for handle
M130021Y
22
Connecting bearings
M130022Y
23
Outer bearing for handle
M130026Y
24
Flange bearing
M130027Y
Drawbar complete
M110057Y
