Construction and function
126746 83
5 Construction and function
5.1 Installation of the lifting system
Sets consisting of 2, 3, 4, 6 or 8 mobile lifting units are required to lift a vehicle.
1
Vehicle
4
Radio module
2
Lifting unit
5
Control panel at the control station
3
Wheel fork for vehicle uptake
[5]
[2]
[4]
[1]
[2]
