Installation and initial commissioning
8.3 Foundation and floor
DANGER
Risk of death and injury from asphalt ground
◼ Only use the lifting system on level, statically tested floor slabs.
Requirements for the concrete floor slab:
◼ Required concrete quality: C20 / 25 with a minimum load-bearing capacity of
20 MPa.
◼ Minimum thickness of the bottom plate 115 mm.
◼ Maximum permissible transverse angle to the vehicle: 1% (10 mm / m).
◼ Maximum permissible longitudinal angle to the vehicle: 2% (20 mm / m).
9 Installation and initial commissioning
DANGER
Risk of death and injury due to improper installation
◼ Installation, maintenance and repair work may only be carried out by
trained and authorised specialists whilst the system is switched off and
secured.
◼ Work on the electrical equipment of the system may only be carried out by
electricians.
◼ Work on hydraulic equipment may only be carried out by qualified
personnel with special knowledge and experience in hydraulics.
