Blizzard Snowplow 760HD

Questions and Answers

J
James ColeAug 18, 2025
Why are the plow functions slow on my Blizzard Automobile Accessories?
- A
  Anna HarrellAug 18, 2025
  If the pump of your Blizzard Automobile Accessories runs slowly, it might be due to several reasons. First, the fluid level in the pump reservoir could be low or leaking; add fluid to within 3/4” from the top of the tank and check for leaks around the pump, manifold, and cylinders. Second, the system pressure may be set too low; adjust the pressure by removing the hex cap on top of the pump and turning the screw clockwise until the system pressure is at 2400PSI. Third, the vehicle’s alternator may not be providing enough amperage; repair or replace the vehicle alternator, noting that the system amperage draw is 135A (145A for 760LT) at 1500PSI. Finally, the pump filter may be clogged; remove the pump tank and thoroughly clean the filter.
T
Taylor CastroAug 20, 2025
Why will my Blizzard Snowplow 760HD Automobile Accessories plow not lift?
- M
  melissa96Aug 20, 2025
  If your Blizzard Automobile Accessories plow will not lift, first ensure that the control station in the cab is properly connected to the vehicle harness. Also, check if the A-frame latch is in the locked (down) position and lift it to the raised position. Additionally, the diode loop harness may be corroded or failed; clean it thoroughly or replace it. Lastly, the coils on the manifold may be damaged. To check, remove the S6 coil, position a screwdriver inside, and push the draw latch connect/disconnect toggle switch upward; if the screwdriver is not magnetically drawn to the coil, replace the coil.
E
Eduardo MooreAug 23, 2025
How to fix headlights that will not switch to the snowplow on my Blizzard Snowplow 760HD Automobile Accessories?
- A
  Amy CalhounAug 23, 2025
  If your Blizzard Automobile Accessories headlights will not switch from the vehicle to the snowplow, verify the headlight/ground relay connector is connected. If the connector is properly attached, replace the headlight relay(s).
M
Matthew JohnsonAug 26, 2025
What causes a Blizzard Snowplow 760HD plow to not lift even with magnification to the S6 coil?
- T
  Troy PriceAug 26, 2025
  If your Blizzard Automobile Accessories plow will not lift, even with magnification to the S6 coil, there may be a hydraulic lock in the manifold. Loosen cartridge valve S6 to relieve pressure and retighten, but do not overtighten (valves should be torqued to a maximum of 24 ft-lbs). Alternatively, the solenoid cartridge valve may be contaminated. Remove any foreign objects that may be obstructing proper valve operation. Replace the valve if it does not operate properly after cleaning.
S
Shane FloresAug 28, 2025
Why is my Blizzard Automobile Accessories plow lowering too slow?
- S
  Sheila RuizAug 28, 2025
  If your Blizzard Automobile Accessories plow lowers too slow, the variable flow control valve is not adjusted properly. Drop the snowplow to the ground before adjusting the flow control to prevent sudden falls that could cause serious injury or death. Turn the flow control valve counterclockwise in small increments and test.
F
flewisAug 30, 2025
Why does my Blizzard Snowplow 760HD plow drop sporadically?
- J
  Joshua RobinsonAug 30, 2025
  If your Blizzard Automobile Accessories plow drops sporadically, the variable flow control valve is likely opened too far. To correct this, drop the snowplow to the ground before adjusting the flow control to prevent sudden falls that could cause serious injury or death. Turn the valve clockwise 1/16 of a turn and test.
A
Arthur VegaSep 2, 2025
Why will my Blizzard Snowplow 760HD Automobile Accessories plow not stay angled when plowing?
- M
  Matthew JacksonSep 2, 2025
  If your Blizzard Automobile Accessories plow will not stay angled when plowing, the angle pressure relief valve may be set too low. Check the pressure relief by testing the valve inline with the cylinder. Attach a tee fitting to the angle cylinder hydraulic adapter and connect the hose and pressure gauge to the tee. The setting should not exceed 3000PSI.
A
Adam JamesSep 4, 2025
What to do if the pump will not turn off on my Blizzard Snowplow 760HD?
- M
  Misty WestSep 5, 2025
  If the pump of your Blizzard Automobile Accessories will not turn off, the solenoid may be damaged. Disconnect the brown/white activation wire from the solenoid; if the problem persists, replace the solenoid. Alternatively, there may be a short in the control or wire harness. Disconnect the control in the cab; if the pump turns off, there is a short in the electrical system.
M
Melissa CollinsSep 7, 2025
How to troubleshoot a pump that will not run on Blizzard Snowplow 760HD Automobile Accessories?
- C
  Cory ChurchSep 7, 2025
  If the pump of your Blizzard Automobile Accessories will not run, first verify that the plow harness is properly connected to the vehicle harness. Next, ensure that the power or ground cables to the battery, pump, or solenoid are properly connected. Clean and lubricate the connections with dielectric grease. If power does not resume, check the continuity of all cables to find the break.
W
wendycooperSep 9, 2025
What to do if the pump will not run with power to the solenoid on my Blizzard Snowplow 760HD?
- V
  Veronica WalkerSep 9, 2025
  If the pump of your Blizzard Automobile Accessories will not run but there is power to the solenoid, make sure that the black ground wire and brown/white activation wire on the solenoid are properly connected. Test for power by initiating any control function except the float. Ensure the POWER rocker switch is in the “ON” position to properly test any plow function. If the solenoid is grounded and no power exists, diagnose the plow & truck harnesses.

Summary

Preface

Safety

Safety Definitions and Labels

Explains the meaning of warning, caution, and instruction labels used in the manual.

Mounting and Dismounting Instructions

Step-by-step guide for attaching and detaching the snowplow using the POWER HITCH™ system.

General Safety Precautions

Detailed safety guidelines for operating and servicing the snowplow to prevent injury.

Hydraulic and Fuse Safety

Safety information related to hydraulic fluid hazards and electrical fuse replacement.

Personal, Fire, and Ventilation Safety

Safety measures for personal protection, fire hazards, and vehicle exhaust ventilation.

Operation

Blade Positioning Controls

Instructions for operating the blade functions: lowered, raised, angled left, and angled right.

Unpacking and Inspection

Serial Number Identification

Guidance on locating and identifying serial number labels for the snowplow and hydraulic unit.

Torque Specifications

SAE and Metric Bolt Torque Values

Torque values for various SAE (J429) and metric bolt grades based on size.

JIC Flare and O-Ring Boss Torque Values

Torque specifications for 37° JIC flare and O-ring boss fittings.

Moldboard & A-Frame Assembly

Mounting Pivot Beam and Kickstand

Steps for attaching the pivot beam, A-frame, and adjusting the kickstand.

Installing Angle and Lift Cylinders

Procedures for installing hydraulic angle and lift cylinders with hoses and adapters.

Connecting Draw Latch and Manifold

Steps to connect the draw latch assembly and install the hydraulic manifold.

Pump and Spring Assembly

Instructions for mounting the pump assembly and attaching extension springs.

General System Schematics

Electrical Schematic

Wiring diagram for the snowplow electrical system.

Hydraulic Schematic

Hydraulic circuit diagram illustrating system flow and components.

Hydraulic Guide

Valve and Hose Port Identification

Identifies hydraulic valve ports and solenoid functions for operation.

Electrical Installation - Snowplow Side

Wiring Plow Components and Covers

Connecting electrical components, switches, and installing covers on the snowplow.

Electrical Schematics

Vehicle & Plow Harness Plug Pinouts

Pin configurations and wire colors for vehicle and plow electrical connectors.

Electrical Schematics - Snowplow Side

Plow Harness Wiring Diagrams

Detailed wiring diagrams and schematics for the plow harness.

Electrical Installation - Vehicle Side

Harness Routing and Contactor Installation

Routing the electrical harness and installing the vehicle power contactor (solenoid).

Vehicle Wiring Steps (Splices, Switches, Power)

Connecting vehicle wiring, lights, switches, and power sources.

Joystick Control and Testing

Installing the joystick control, connecting system power, and performing functional tests.

Electrical Schematics - Vehicle Side

Vehicle Harness Diagrams

Diagrams illustrating the vehicle electrical harness layout and connections.

Main Lighting Harness Schematics

Schematics detailing the connections for the main lighting harness.

POWER HITCH System Instructions

Mounting and Dismounting Procedures

Step-by-step instructions for mounting and dismounting the POWER HITCH system.

Testing Your Snowplow

Hydraulic System and POWER HITCH Testing

Procedures for filling the reservoir, connecting, and testing the hydraulic system and POWER HITCH.

Plow Function and Leak Testing

Testing plow functions, headlights, and checking the hydraulic system for oil leaks.

Headlight Aiming

Headlight Aiming Procedure

Steps for correctly aiming snowplow headlights using a screen and specified measurements.

Maintenance

Periodic and Yearly Maintenance Schedule

Schedule and tasks for regular snowplow maintenance activities.

Storage and Lifting Procedures

Guidelines for proper storage of the snowplow and safe lifting procedures.

Technical Specifications

Model Specifications (760 LT, 760 HD, 800 HD, 860 HD)

Detailed specifications for each snowplow model including dimensions and weight.

Troubleshooting

Pump and Latch Troubleshooting

Solutions for common problems related to the pump and A-frame latch.

Plow Function and Headlight Troubleshooting

Solutions for issues with plow angling, lowering, and headlight operation.

Parts Lists

Moldboard & Wing Parts

Diagram and list of components for the moldboard and wings.

A-Frame & Pivot Beam Parts

Diagram and list of components for the A-frame and pivot beam assemblies.

Power Unit Parts

Diagram and list of components for the power unit assembly.

Lights, Draw Latch & Control Parts

Diagram and list of components for lights, draw latch, and control systems.

Harnesses, Accessories & Kits

Information and parts lists for snowplow harnesses, accessories, and kits.

Notes
