Operation
name
Operation
and note
Remove SUB
PCBA ,
Speaker and Microphone
1
Remove SUB PCBA with tweezers
2:Remove
Speaker with Hot Air Gun
3:Remove
Microphone with
Hot Air
Gun
S6061C_S4 disassembling
procedure have been
completed
S6061C_S4 disassembling
procedure have been completed
