Blu Studio Mega - Page 9

NO.
Operation
name
Operation
and note
4
Remove
B cover
1.Using your fingernail insert into
gap between A cover and B
cover ,and sliding along the around
of A cover to release hook, then B
-
cover will be removed.
5
Remove
Main PCBA
0:Remove 2 PCS screws
1:Disconnect the TP connector
2:Remove side key reinforcement plate
3:Remove the Motor
4:Disconnect
the LCD connector
6
Remove main
camera and second
camera
1:Remove
main camera with tweezers
2.Remove second camera with tweezers
