To Next PageTo Next PageWhat does it mean if Blue Giant Industrial Electrical restraint is engaged but light is red?
If the restraint is engaged on your Blue Giant Industrial Electrical system, but the inside light is still red, the dock leveler may not be deployed, meaning the dock interlock sensor still detects the lip. Alternatively, the dock interlock might be damaged and need replacement.
Why Blue Giant Industrial Electrical restraint extends but doesn't lower?
If the restraint on your Blue Giant Industrial Electrical system extends fully, but does not lower, the tilt antenna may be out of adjustment; set it to the proper setup position. The SV1 may not be energizing; check the connections and proper lead termination. The SV1 stem/cartridge might not be shifting; replace the solenoid. The SV3 may not be energizing; check connections and proper lead termination. The SV3 stem/cartridge might not be shifting; replace the solenoid.
Why Blue Giant Industrial Electrical restraint lowers but doesn't extend?
If the restraint on your Blue Giant Industrial Electrical system fully lowers, but does not extend, the SV1 solenoid might be active; check the wiring. The SV1 stem/cartridge could be damaged; replace the solenoid. It's also possible that the hydraulic oil is low; fill it to the proper level. The hook down antenna might not be in range; adjust it to the proper setting. Additionally, the SV2 solenoid could be active; check the wiring. The SV2 solenoid stem/cartridge might be damaged; replace the solenoid. Finally, the SV4 unloader solenoid could be faulty; replace the valve.
Why Blue Giant Industrial Electrical restraint extends but doesn't fully lower?
If the restraint on your Blue Giant Industrial Electrical system does not fully lower, but fully extends, the hook could be blocked; check for foreign debris. The tilt antenna may be out of adjustment; set it to the proper setup position. The pressure relief valve might be set too low; adjust it to the proper settings.
Why Blue Giant Industrial Electrical restraint won't raise but lowers and extends?
If the restraint on your Blue Giant Industrial Electrical lowers and extends fully but will not raise, and the motor is running in pressure relief, the solenoid SV3 might be electrically on; check for shorts. The SV3 solenoid stem/cartridge may not be shifting when de-energized, requiring you to replace the solenoid. A tilt cylinder internal spring could be broken, so replace the cylinder. Mechanical binding may also be occurring; check all pivot points for possible seizing or foreign debris. Finally, the tilt antenna may be malfunctioning; check the sensor and antenna for proper setup.
Why Blue Giant Industrial Electrical restraint does not fully extend?
If the restraint on your Blue Giant Industrial Electrical system does not fully extend, the hydraulic oil might be too low. Add hydraulic oil, being careful not to overfill the tank. Add oil to the tank with both hydraulic cylinders retracted.
Why Blue Giant Industrial Electrical LED lights are off but LCD is working?
If the restraint on your Blue Giant Industrial Electrical system works, but the LED cover lights are not lit while the LCD display is working, the power source for the lights may be damaged. In this case, replace the control board.
What to do if Blue Giant Industrial Electrical hook releases but doesn't retract?
If the restraint hook on your Blue Giant Industrial Electrical system releases from the ICC bar and lowers, but does not retract, the SV1 solenoid may still be active; check the wiring. The SV1 solenoid stem/cartridge could be damaged, requiring you to replace the solenoid. The SV2 solenoid might not be active, so check its wiring. The SV2 solenoid stem/cartridge could also be damaged, so replace the solenoid if necessary.
Why Blue Giant Industrial Electrical hook doesn't hold ICC bar tightly?
If the restraint hook on your Blue Giant Industrial Electrical system doesn't hold the ICC bar tightly and the inside lights turn green, the pressure switch may be set too low. Adjustment should be performed by qualified personnel. Another cause might be the use of the wrong hydraulic oil; replace it with an approved type.
What to do if the Blue Giant Industrial Electrical restraint hook will not rise?
If the restraint hook on your Blue Giant Industrial Electrical system won't rise when you press the ENGAGE button, there are several potential causes. It could be due to faulty wiring, a connection issue, or a broken wire, in which case you should refer to the electrical wiring diagram. There might be a power source problem; check the incoming voltage against the data nameplate voltage. The restraint apparatus could be seized, so inspect it for foreign objects like broken wooden pallet splitters. Also, the controls might be in bypass mode, so try pressing the RELEASE button and then the ENGAGE button.
Section to record dealer, serial number, date in service, and units for warranty validation.
Details on Blue Giant product warranty, validation process, and support contact information.
Manufacturer's disclaimer regarding liability for damage or injury due to product use or modifications.
Information on checking for transport damage and reporting it within 48 hours of receipt.
Outlines owner's duties for safe operation, training, maintenance, and reporting issues.
Highlights critical safety instructions and warnings for operating the vehicle restraint.
Explains the function of touch buttons and keypad on the Blue Genius™ control panel for operation.
Describes the vehicle restraint's purpose, operation, and standard communication lights.
Details the function of the temporary 'STOP' button to halt operation and exit the mode.
Describes the initial state of the restraint and dock leveler before operation.
Sequence of events when a truck reverses into position at the dock leveler.
Step-by-step guide on how to secure the vehicle's ICC bar using the restraint.
Instructions for deploying the dock leveler after the vehicle is secured.
Procedure for disengaging the vehicle restraint after loading/unloading is complete.
Guide for bypassing the restraint function when an ICC bar is missing or damaged.
Steps to release the override feature and return the restraint to its parked position.
Recommendations for scheduled maintenance to ensure safe operation and prolong component life.
Daily checks required by the operator to verify the restraint is safe for use.
Specifies approved hydraulic oils for normal and extreme low-temperature conditions.
A checklist for performing periodic maintenance and recording inspection findings.
List and identification of standard components recommended for replacement.
Details on retainer assemblies used as component shields for the vehicle restraint.
List of components included with the RVR303 assembly upon shipment, with part numbers and weights.
Provides key physical dimensions and specifications for the vehicle restraint and extension box.
Provides front and side view dimensions for the junction box used with the remote I/O.
Sample wiring diagram for a 115V single-phase installation of the RVR303.
Sample wiring diagram for a 230-575V three-phase installation of the RVR303.
