Blue point BP301 - Page 15

BP301 www.bpfasteners.com Page 15
Item #
PART #
DESCRIPTION
Item #
PART #
DESCRIPTION
1
BP301-01
Spall guard
14
BP301-14
Tool body
2
BP301-02
Base Plate
15
BP301-15
Push Pin
3
BP301-03
Shear clip
16
BP301-16
Trigger assembly
4
BP301-04
Fastener guide
16-1
BP301-16-1
Advance Arm
5
BP301-05
Piston with piston ring
17
BP301-17
Screw, Trigger
6
BP301-06
Piston sleeve
18
BP301-18
Sear holder
7
BP301-07
Bolt (M6 X 18) 2pcs
19
BP301-19
Sear spring
8
BP301-08
Stop (PAWL)
20
BP301-20
Sear
9
BP301-09
Annular spring
21
BP301-21
Firing pin assembly
10
BP301-10
Ball (Dia. 6mm)
22
BP301-22
Firing pin spring
11
BP301-11
Liner
23
BP301-23
Sear holder return spring
12
BP301-12
Detent Ball 2pcs
24
BP301-24
Cover plug
13
BP301-13
Detent spring 2pcs
25
BP301-25
Rubber handle assembly
