17
Service Parts for Model YA667B(continued) - Air Hyd. Pump
Parts List for Model YA667B
Part# Description Qty
Part# Description Qty
Part# Description Qty
200003h Gasket 1
200472 Screw 2
201110 Lockwasher 4
201479 Lockwasher 2
201733 Plug 1
201779 Lockwasher 2
201784 Lockwasher 1
201808 Rivet 2
203198h Ball (7/32" O.D.) 1
203199h Ball (1/4" O.D.) 1
203200h Ball (9/32" O.D.) 1
203201h Ball (5/16" O.D.) 1
203202 Ball (11/32" O.D.) 1
203205h Ball (7/16" O.D.) 1
203299 Jam Nut 4
203313 Jam Nut 2
203332 Nut 1
203344 Jam Nut 2
204270 Washer 2
204277 Washer 1
204301 Washer 1
204303 Washer 1
204343 Washer 4
204372 Washer 1
204444 Cotter Pin 3
204461 Cotter Pin 1
204842h Copper Gasket 1
209964 Lockwasher 2
210225 Spacer 1
210311 Pipe Plug 4
210411h Washer 1
211341 Rivet 1
212227 Release Valve 1
213152h Packing Ring 2
213171h Packing Ring 2
213639 Bolt 1
214538 Groove Pin 4
214555h O-ring 1
214699 Bushing 1
214700 Handle segment Assy. 1
216645 Pin 1
216646 Pump Pin 1
218988 Roll Pin 1
219451 Hex Nut 2
220769 Cross Pin 1
221013# U-cup Packing 1
221377 Roll Pin 1
221739h Poppet 1
221740 Ball Stop Plug (7/16" L)1
221742 Ball Stop Plug (3/4" L)1
221764h Ram Quad Ring 1
221766 Cylinder 1
221770 Low Pressure Pump 1
221771h Washer 1
221772h Quad ring 1
221778 Washer 2
221798 Retainer Ring 4
221817 Retainer Ring 2
221820 Retaining Ring 1
221823 Parallel Link 2
...Continue on next page (page 18)
242162
Piston Assembly
242160
Air-HydraulicPump Assembly
Piston
Assembly
242162
35100007
To Next Page
